Panasonic CS-E12RB4UW Service Manual

14
5.2 Outdoor Unit
5.2.1 CU-E12RB4U
5.2.2 CU-E18RB4U
<Side View>
<Side View> <Front View>
<Top View>
Unit : mm (inch)
780 (30-23/32)
24.4 (1)
67.6
(2-5/8)
11. 5
(1/2)
540 (21-9/32)
(18
(3/4))
(69.6
(2-3/4))
(61.6
(2-3/8))
289 (11-13/32)
34.5
(1-3/8)
155
(6-1/8)
84.8
(3-3/8)
570 (22-1/2)
(104.7
(4-1/8))
104.9
(4-1/8)
60.5
(2-3/8)
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
Space necessary for
installation
Anchor Bolt Pitch
320 (12-5/8) x 570 (22-1/2)
100 cm (39-3/8)
10 cm (3-7/8)
10 cm (3-7/8)
Space necessary for
installation
Anchor Bolt Pitch
360.5 (14-3/16) x 613 (24-9/64)
100 cm (39-3/8)
10 cm (3-7/8)
10 cm (3-7/8)
27.5
(1-5/64)
613 (24-1/8)
131
(5-5/32)
70
(2-3/4)
38 (1-1/2)
82
(3-7/32)
152
(5-31/32)
360.5 (14-3/16)
875 (34-15/32)
(131
(5-5/32))
<Top View>
795 (31-5/16)
59
(2-5/16)
320 (12-5/8)
<Side View>
<Side View>
Unit : mm (inch)
<Front View>
75
(2-61/6 4)
64
(2-17/32)
(25
(31/32))
70
(2-3/4)
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
