10.2 Outdoor Unit
10.2.1 Main Printed Circuit Board
10.2.1.1 CU-E12RB4U
CN-DCFM
F
G
1
CN-STM
CN4
CN5
CN-TANK
CN-TH
CN-HOT
CURRENT
TRANSFORMER
(CT)
DAT A
AC-WHT
AC-BLK
POWER
TRANSISTOR
(IPM)
