17. Technical Data
Technical data provided are based on the air conditioner running under free frequency.
17.1 Cool Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Cool mode at 16°C (60.8°F)
Voltage: 208V/230V
17.1.1 CS-E12RB4UW CU-E12RB4U
Rated frequency (compressor speed is fixed during forced heating or cooling for capacity measurement and
diagnosis purpose)
Indoor (°C / °F) Outdoor (°C / °F)
DB WB -17.8 (0) -10 (14) 0 (32) 5 (41)
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
(80.6)
19.0 (66.20) 13351 11952 847 13351 11952 861 13287 12058 839 13563 12308 793
22.0 (71.60) 14108 8496 901 14108 8496 915 14195 8620 861 15326 9157 643
23
(73.4)
15.7 (60.26) 12494 12369 809 12494 12369 822 12076 11955 879 13679 13542 706
18.4 (65.12) 13142 8464 830 13142 8464 843 12728 8319 883 13447 8754 745
20
(68.0)
13.3 (55.94) 11872 11753 875 11872 11753 889 11450 11335 911 10493 10388 625
15.8 (60.44) 12234 8416 892 12234 8416 906 12267 8355 875 11045 7881 592
Indoor (°C / °F) Outdoor (°C / °F)
DB WB 16 (60.8) 25 (77) 35 (95) 46 (114.8)
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
(80.6)
19.0 (66.20) 14114 11997 704 12467 11052 1028 11900 11171 1150 9751 9166 1381
22.0 (71.60) 14575 8575 701 13606 7761 983 12653 7756 1130 10382 6364 1357
23
(73.4)
15.7 (60.26) 12517 12392 788 11293 11180 1055 10952 10842 1165 8986 8896 1399
18.4 (65.12) 13239 8489 760 12409 7825 1026 11234 8006 1149 9218 6569 1380
20
(68.0)
13.3 (55.94) 9276 9183 348 9194 9102 797 10064 9963 1169 8257 8175 1404
15.8 (60.44) 10636 7480 671 11052 7657 1051 10228 7684 1158 8392 6305 1391
17.1.2 CS-E18RB4UW CU-E18RB4U
Rated frequency (compressor speed is fixed during forced heating or cooling for capacity measurement and
diagnosis purpose)
Indoor (°C / °F) Outdoor (°C / °F)
DB WB -17.8 (0) -10 (14) 0 (32) 5 (41)
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
(80.6)
19.0 (66.20) 21585 18070 1223 21563 18051 1208 21536 18375 1172 21477 17969 1162
22.0 (71.60) 24761 14770 1069 24736 14755 1056 23579 14434 1224 21993 13533 1221
23
(73.4)
15.7 (60.26) 18995 18805 1350 18976 18787 1333 20174 19972 1110 19232 19040 1230
18.4 (65.12) 21236 13901 1235 21215 13887 1220 23638 14975 966 22023 13104 1284
20
(68.0)
13.3 (55.94) 16722 16554 1339 16705 16538 1322 16597 16431 878 15998 15838 1050
15.8 (60.44) 16679 12254 1546 16662 12242 1527 17460 12654 914 18874 13512 902
Indoor (°C / °F) Outdoor (°C / °F)
DB WB 16 (60.8) 25 (77) 35 (95) 46 (114.8)
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
(80.6)
19.0 (66.20) 21393 18203 1146 18720 16185 1562 17500 16117 1700 12025 11063 1528
22.0 (71.60) 22132 14479 1150 20357 12809 1579 19332 10069 1722 13269 6911 1548
23
(73.4)
15.7 (60.26) 19837 19638 1146 17320 17147 1533 16032 15871 1795 11004 10894 1614
18.4 (65.12) 21651 13832 1149 19039 12328 1549 17649 11957 1828 12114 8207 1643
20
(68.0)
13.3 (55.94) 17342 17168 959 16223 16060 1531 14783 14635 1764 10147 10045 1586
15.8 (60.44) 19740 15389 1555 19440 13413 1966 16513 6641 1921 11334 4559 1727
