16.2.2 CU-E18RB4U
Caution! When handling electronic controller, be careful of electrostatic discharge.
1 Remove the 4 screws of the Top Panel.
Fig. 1
2 Remove the 10 screws of the Front Panel.
Fig. 2
3 Remove the Top Cover of the Electronic
Controller.
Fig. 3
4 Remove the Control Board.
Fig. 4
5 Remove the 8 screws of the Electronic
Controller.
Fig. 5
Caution! When handling electronic controller, be careful of
electrostatic discharge.
Sc
r
ew
s
Screws
Top Panel
S
c
re
w
s
Screws
Screws
Front
Panel
T
o
p
C
o
v
e
r
Release
6terminal
connectors
Control Board
R
elease 6•
c
onnectors
R
e
l
e
as
e
t
h
e
H
o
o
k
s
S
c
r
e
ws
Screws
Electronic
Controller
