92
17.2 Heat Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Heat mode at 30°C (86°F)
Voltage: 208V/230V
17.2.1 CS-E12RB4UW CU-E12RB4U
Rated frequency (compressor speed is fixed during forced heating or cooling for capacity measurement and
diagnosis purpose)
Indoor (°C / °F) Outdoor (°C / °F)
DB -15 (5) -8.3 (17.06) 1.7 (35.06) 8.3 (46.94) 12 (53.6) 23.9 (75.02)
TC IP TC IP TC IP TC IP TC IP TC IP
24 (75.2) 7417 1084 9884 1261 12503 1370 13681 1371 13151 1395 15282 1352
20 (68.0) 7892 1075 10567 1256 12860 1344 13600 1360 13901 1364 16153 1323
16 (60.8) 7534 1058 10858 1243 13911 1355 14623 1396 13561 1341 15759 1300
17.2.2 CS-E18RB4UW CU-E18RB4U
Rated frequency (compressor speed is fixed during forced heating or cooling for capacity measurement and
diagnosis purpose)
Indoor (°C / °F) Outdoor (°C / °F)
DB -15 (5) -8.3 (17.06) 1.7 (35.06) 8.3 (46.94) 12 (53.6) 23.9 (75.02)
TC IP TC IP TC IP TC IP TC IP TC IP
24 (75.2) 9103 1891 11867 2160 15151 2177 19861 2474 20737 2460 22347 2362
20 (68.0) 9214 1821 11903 2078 15371 2087 20400 2340 21563 2360 23237 2267
16 (60.8) 9050 1740 12006 1986 15536 1999 20894 2212 22141 2235 23861 2146
17.2.3 CS-E12RB4UW CU-E12RB4U
Maximum Capacity
Indoor (°C / °F) Outdoor (°C / °F)
DB -15 (5) -8.3 (17.06) 1.7 (35.06) 8.3 (46.94) 12 (53.6) 23.9 (75.02)
TC IP TC IP TC IP TC IP TC IP TC IP
24 (75.2) 9472 1433 10805 1505 14107 1663 16355 1724 15698 1738 17556 1623
20 (68.0) 10062 1420 11553 1499 14510 1631 16290 1710 16593 1700 18557 1588
16 (60.8) 9395 1396 11871 1484 15695 1645 17482 1755 16188 1671 18104 1561
17.2.4 CS-E18RB4UW CU-E18RB4U
Maximum Capacity
Indoor (°C / °F) Outdoor (°C / °F)
DB -15 (5) -8.3 (17.06) 1.7 (35.06) 8.3 (46.94) 12 (53.6) 23.9 (75.02)
TC IP TC IP TC IP TC IP TC IP TC IP
24 (75.2) 11788 2684 14163 2756 17533 2711 20460 2643 21354 2628 23029 2477
20 (68.0) 11949 2594 14206 2653 17788 2560 21002 2500 22204 2522 23946 2377
16 (60.8) 11689 2485 14329 2540 17979 2474 21524 2363 22800 2388 24589 2251
TC - Total Cooling Capacity (Btu/h)
IP - Input Power (W)
