Panasonic CS-E12RB4UW - Heat Mode Outdoor Air Temperature Characteristic

95
18.2 Heat Mode Outdoor Air Temperature Characteristic
Condition
 Indoor room temperature: 20°C (68°F) Dry Bulb/ -°C Wet Bulb
 Unit setting: Standard piping length, forced heating at 30°C (86°F), Hi fan
 Compressor frequency: Rated for Heating operation
 Piping Length: 7.5 m (24.6 ft)
 Voltage: 208V/230V
18.2.1 CS-E12RB4UW CU-E12RB4U
Outlet Air
°C (°F)
Current
(A)
Gas Side Piping
Pressure MPa (PSI)
208
230
33.0 (91.4)
34.0 (93.2)
35.0 (95.0)
36.0 (96.8)
37.0 (98.6)
38.0 (100.4)
39.0 (102.2)
40.0 (104.0)
41.0 (105.8)
42.0 (107.6)
43.0 (109.4)
Outdoor Air Temperature °C (°F)
-15
(4.9)
-10
(14)
-5
(23)
0
(32)
5
(41)
10
(50)
15
(59)
20
(68)
25
(77
)
5.000
5.200
5.400
5.600
5.800
6.000
6.200
6.400
6.600
6.800
7.000
2.000 (290.075)
2.100 (304.579)
2.200 (319.083)
2.300 (333.586)
2.400 (348.090)
2.500 (362.594)
2.600 (377.098)
2.700 (391.601)
2.800 (406.105)
2.900 (420.609)
Outdoor Air Temperature °C (°F)
-15
(4.9)
-10
(14)
-5
(23)
0
(32)
5
(41)
10
(50)
15
(59)
20
(68)
25
(77
)
Outdoor Air Temperature °C (°F)
-15
(4.9)
-10
(14)
-5
(23)
0
(32)
5
(41)
10
(50)
15
(59)
20
(68)
25
(77
)
