5
2. Specifications
Model
Indoor CS-E12RB4UW
Outdoor CU-E12RB4U
Performance Test Condition ARI
Power Supply
Phase, Hz Single, 60
V 208 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 1.20 3.48 3.90 1.20 3.48 3.90
BTU/h 4100 11900 13300 4100 11900 13300
kcal/h (Frig./h) – – – – – –
Running Current A – 6.0 – – 5.2 –
Input Power W 250 1.15k 1.32k 250 1.15k 1.32k
Annual Consumption kWh – – – – – –
EER
W/W 4.80 3.03 2.95 4.80 3.03 2.95
BTU/hW 16.40 10.30 10.05 16.40 10.30 10.05
kcal/hW – – – – – –
Power Factor % – 92 – – 96 –
Indoor Noise (H / L / QLo)
dB-A 34 / 28 / 25 34 / 28 / 25
Power Level dB 50 / – / – 50 / – / –
Outdoor Noise (H / L / QLo)
dB-A 51 / – / – 51 / – / –
Power Level dB 66 / – / – 66 / – / –
Heating
Capacity
kW 1.20 3.99 4.77 1.20 3.99 4.77
BTU/h 4100 13600 16300 4100 13600 16300
kcal/h (Frig./h) – – – – – –
Running Current A – 6.9 – – 6.1 –
Input Power W 230 1.36k 1.71k 230 1.36k 1.71k
COP
W/W 5.22 2.93 2.79 5.22 2.93 2.79
BTU/hW 17.80 10.00 9.50 17.80 10.00 9.50
kcal/hW – – – – – –
Power Factor % – 95 – – 97 –
Indoor Noise (H / L / QLo)
dB-A 34 / 30 / 27 34 / 30 / 27
Power Level dB 50/ – / – 50 / – / –
Outdoor Noise (H / L / QLo)
dB-A 51 / – / – 51 / – / –
Power Level dB 66 / – / – 66 / – / –
Max Current (A) / Max Input Power (W) 7.80 / 1.71k
Starting Current (A) 6.9
Compressor
Type Hermetic Motor (Rotary)
Motor Type Brushless (4-poles)
Output Power W 700
