Panasonic CS-E12RB4UW Service Manual

6
Model
Indoor CS-E12RB4UW
Outdoor CU-E12RB4U
Indoor Fan
Type BACKWARD FAN
Material ABS
Motor Type DC / Transistor (8-poles)
Input Power W –
Output Power W 40
Speed
QLo
Cool rpm 330
Heat rpm 410
Lo
Cool rpm 370
Heat rpm 460
Me
Cool rpm 460
Heat rpm 540
Hi
Cool rpm 560
Heat rpm 620
SHi
Cool rpm 600
Heat rpm 650
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 830
Heat rpm 820
Min Circuit Ampacity 15.0
Max. Overcurrent Protection 15.0
SEER / HSPF 18.00 / 9.00
Moisture Removal L/h (Pt/h) 1.9 (4.0)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 6.7 (240)
Heat m
3
/min (ft
3
/min) 7.7 (270)
Lo
Cool m
3
/min (ft
3
/min) 7.3 (260)
Heat m
3
/min (ft
3
/min) 8.5 (300)
Me
Cool m
3
/min (ft
3
/min) 8.8 (310)
Heat m
3
/min (ft
3
/min) 9.8 (350)
Hi
Cool m
3
/min (ft
3
/min) 10.5 (370)
Heat m
3
/min (ft
3
/min) 11.1 (390)
SHi
Cool m
3
/min (ft
3
/min) 11.2 (400)
Heat m
3
/min (ft
3
/min) 11.6 (410)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 31.0 (1095) 31.0 (1095)
Heat m
3
/min (ft
3
/min) 31.0 (1095) 31.0 (1095)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (320)
Refrigerant Type g (oz) R410A, 980 (34.6)
Dimension
Height (I/D / O/D /
PANEL)
mm (inch) 260 (10-1/4) / 540 (21-9/32) / 51 (2-1/32)
Width (I/D / O/D /
PANEL)
mm (inch) 575 (22-21/32) / 780 (30-23/32) / 700 (27-9/16)
Depth (I/D / O/D /
PANEL)
mm (inch) 575 (22-21/32) / 289 (11-13/32) / 700 (27-9/16)
Weight
Net (I/D / O/D /
PANEL)
kg (lb) 18 (40) / 37 (82) / 2.5 (6)
