2 Specifications
2.1. CS-PC18GKF CU-PC18GKF
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition NEW JIS
C
O
O
L
I
N
G
Capacity
kW 5.28 - 5.28
BTU/h 18,000 - 18,000
EER
W/W 2.65 - 2.58
BTU/hW 9.05 - 8.79
Noise Level dB (A) High 45 - 45, Low 41 - 41 High 54 - 56
Moisture Removal
l/h 2.9
pt/h 6.1
Air Volume
Lo
m
3
/min (ft
3
/min)
12.5 (442) - 12.5 (442) —
Me
m
3
/min (ft
3
/min)
14.5 (512) - 14.5 (512) —
Hi
m
3
/min (ft
3
/min)
15.8 (558) - 15.8 (558) 30.3 (1,070) - 31.3 (1,100)
Refrigeration Control Device — Capillary Tube
Refrigeration Oil
cm
3
—
SUNISO 4GDID or ATMOS M60 or
ATMOS 56M (450)
Refrigerant (R-22) g (oz) — 980 (34.6)
Dimension
Height mm (inch) 275 (10-13/16) 540 (21-1/4)
Width mm (inch) 998 (39-9/32) 780 (30-23/32)
Depth mm (inch) 230 (9-1/16) 289 (11-3/8)
Net Weight kg (lbs) 11.0 (24) 39.0 (86)
Pipe Diameter
Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 25 (82.0)
Height Difference m (ft) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type —
Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 1.5
Fan
Type Cross-Flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (4-poles)
Input Power W — 62 - 70
Output Power W 30 35
Fan Speed
Lo rpm 1,150 - 1,150 —
Me rpm 1,330 - 1,330 —
Hi rpm 1,450 - 1,450 830 - 855
Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Blue Coated)
Fin Type Slit Fin Corrugated Fin
Row x Stage x FPI 2 x 15 x 21 2 x 24 x 16
Size (W x H x L) mm 810 x 315 x 25.4
702 x 504 x 25.4
722
Air Filter
Material P. P. HONEY COMB —
Type One-Touch —
