6
2.2. CS-PC24GKF CU-PC24GKF
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition NEW JIS
C
O
O
L
I
N
G
Capacity
kW 7.03 - 7.03
BTU/h 24,000 - 24,000
EER
W/W 2.74 - 2.60
BTU/hW 9.34 - 8.89
Noise Level dB (A) High 48 - 49, Low 42 - 42 High 59 - 61
Moisture Removal
l/h 4.0
pt/h 8.5
Air Volume
Lo
m
3
/min (ft
3
/min)
13.9 (490) - 13.9 (490) 26.6 (940) - 30.2 (1,070)
Me
m
3
/min (ft
3
/min)
15.5 (550) - 15.5 (550) —
Hi
m
3
/min (ft
3
/min)
17.4 (610) - 17.4 (610) 52.0 (1,840) - 54.0 (1,910)
Refrigeration Control Device — Capillary Tube
Refrigeration Oil
cm
3
—
SUNISO 4GDID or ATMOS M60 or
ATMOS 56M (1,130)
Refrigerant (R-22) g (oz) — 1,400 (49.4)
Dimension
Height mm (inch) 275 (10-13/16) 750 (29-17/32)
Width mm (inch) 998 (39-9/32) 875 (34-7/16)
Depth mm (inch) 230 (9-1/16) 345 (13-19/32)
Net Weight kg (lbs) 11.0 (24) 58.0 (128)
Pipe Diameter
Gas mm (inch) 15.8 (5/8)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 25 (82.0)
Height Difference m (ft) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type —
Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 2.2
Fan
Type Cross-Flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (6-poles)
Input Power W — 148 - 166
Output Power W 30 80
Fan Speed
Lo rpm 1,310 - 1,310 440 - 500
Me rpm 1,460 - 1,460 —
Hi rpm 1,640 - 1,640 860 - 890
Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Blue Coated)
Fin Type Slit Fin Corrugated Fin
Row x Stage x FPI 2 x 15 x 21 2 x 34 x 18
Size (W x H x L) mm 810 x 315 x 25.4
815 x 714 x 25.4
835
Air Filter
Material P. P. HONEY COMB —
Type One-Touch —
To Next Page
