Panasonic CS-S18TKV Service Manual

11
3. Location of Controls and Components
3.1 Indoor Unit
3.2 Outdoor Unit
3.3 Remote Control
Human Activity Sensor
Horizontal airflow direction louver
• Do not adjust by hand.
Vertical airflow direction louver
• Do not adjust by hand.
Air Filters
Aluminium Fin
Auto OFF/ON button
• Use when remote control is misplaced or
a malfunction occurs.
Sunlight sensor and
remote control receiver
Front Panel
nanoe-G GENERATOR
• Do not touch during operation.
Indicator
(Green)
(Orange)
(Green)
(Blue)
POWER
TIMER
ECONAVI
nanoe-G
Air inlet (rear)
A
ir inlet (side)
Air outlet
AIR CONDITIONER
ON
OFF
SET
TIMER
CANCEL
OFF/ON
FAN SPEED
MODE
SLEEP
QUIET
AIR SWING
TEMP
OFF/ON
A
IR C
O
NDITI
O
NE
R
O
N
O
FF
S
ET
TIME
R
C
ANCEL
T
E
M
P
O
FF/
O
N
Remote control
display
OFF/ON
iAUTO-X operation
ECONAVI operation
nanoe-G operation
Airflow direction selection
Temperature setting
Fan speed selection
Timer setting
Clock setting
Operation mode
Sleep operation
Quiet operation
Check
