19
5.3 CS-S28TKV CU-S28TKV
STRAINER
HEAT EXCHANGER
(CONDENSER)
COMPRESSOR
EXPANSION VALVE
LIQUID
SIDE
ROODTUOROODNI
2-WAY
VALVE
PIPE
TEMP.
SENSOR
INTAKE
TEMP.
SENSOR
HEAT EXCHANGER
(EVAPORATOR)
GAS
SIDE
COOLING
3-WAY
VALVE
INTAKE
TEMP.
SENSOR
PIPE
TEMP.
SENSOR
COMPRESSOR
TEMP. SENSOR
RECEIVER
