17. Technical Data
17.1 Operation Characteristics
17.1.1 CS-S9TKV CU-S9TKV
 Cooling Characteristic
o Room temperature: 27°C (DBT), 19°C (WBT)
o Operation condition: High fan speed
o Piping length: 5.0 m
o Compressor Frequency = Fc
13.800
14.000
14.200
14.400
14.600
14.800
15.000
15.200
15.400
15.600
30 31 32 33 34 35 36 37 38 39 40 41 42 43
Indoor Discharge
Air Temperature (°C)
Outdoor Air Temperature (°C)
220
2.200
2.300
2.400
2.500
2.600
2.700
2.800
2.900
30 31 32 33 34 35 36 37 38 39 40 41 42 43
Cooling
Capacity (kW)
Outdoor Air Temperature (°C)
3.100
3.200
3.300
3.400
3.500
3.600
3.700
3.800
3.900
4.000
30 31 32 33 34 35 36 37 38 39 40 41 42 43
Current
(A)
Outdoor Air Temperature (°C)
1.000
1.010
1.020
1.030
1.040
1.050
30 31 32 33 34 35 36 37 38 39 40 41 42 43
Gas Side Piping
Pressure (MPa)
Outdoor Air Temperature (°C)
