Panasonic CS-S18TKV Service Manual

5
2. Specification
Model
Indoor CS-S9TKV CS-S12TKV
Outdoor CU-S9TKV CU-S12TKV
Performance Test Condition JIS JIS
Power Supply
Phase, Hz Single, 60 Single, 60
V 220 220
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.84 2.65 3.20 0.92 3.23 4.00
BTU/h 2860 9040 10900 3140 11000 13600
kJ/h 3020 9540 11520 3310 11630 14400
Running Current A – 3.4 – – 4.1 –
Input Power W 225 695 870 260 855 1.14k
EER
W/W 3.73 3.81 3.68 3.54 3.78 3.51
BTU/hW 12.71 13.01 12.53 12.08 12.87 11.93
kJ/hW 13.42 13.73 13.24 12.73 13.60 12.63
Power Factor % – 93 – – 90 –
Indoor Noise (H / L / QLo) dB-A 36 / 26 / 23 38 / 28 / 25
Outdoor Noise (H / L / QLo) dB-A 46 / – / – 47 / – / –
Max Current (A) / Max Input Power (W) 5.5 / 1.07k 7.4 / 1.37k
Starting Current (A) 3.4 4.1
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Output Power W 500 650
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type DC / Transistor (8 poles) DC / Transistor (8 poles)
Input Power W 47.3 47.3
Output Power W 40 40
Speed
QLo rpm 650 700
Lo rpm 750 800
Me rpm 920 970
Hi rpm 1080 1140
SHi rpm 1180 1260
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type AC / Induction (6 poles) AC / Induction (6 poles)
Input Power W – –
Output Power W 20 27
Speed Hi rpm 770 950
Moisture Removal L/h (Pt/h) 1.6 (3.4) 1.8 (3.8)
Indoor Airflow
QLo m
3
/min (ft
3
/min) 5.5 (194) 6.0 (212)
Lo m
3
/min (ft
3
/min) 6.6 (233) 7.1 (251)
Me m
3
/min (ft
3
/min) 8.4 (297) 8.9 (314)
Hi m
3
/min (ft
3
/min) 9.9 (350) 10.7 (380)
SHi m
3
/min (ft
3
/min) 11.2 (395) 12.1 (427)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 22.0 (775) 31.6 (1120)
