Panasonic CS-S18TKV Service Manual

6
Model
Indoor CS-S9TKV CS-S12TKV
Outdoor CU-S9TKV CU-S12TKV
Refrigeration
Cycle
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
FV50S (250) FV50S (320)
Refrigerant Type g (oz) R410A, 820 (28.9) R410A, 790 (27.9)
Dimension
Height (I/D / O/D) mm (inch) 295 (11-5/8) 511 (20-1/8) 295 (11-5/8) 542 (21-11/32)
Width (I/D / O/D) mm (inch) 919 (36-3/16) 650 (25-19/32) 919 (36-3/16) 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 194 (7-21/32) 230 (9-1/16) 194 (7-21/32) 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 10 (22) 21 (46) 10 (22) 29 (64)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5.0 (16.4) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 15 (0.2) 15 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16.7 16.7
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coated) Aluminium (Pre Coated)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 21 2 × 15 × 21
Size (W × H × L) mm 610 × 315 × 25.4 610 × 315 × 25.4
Outdoor Heat
Exchanger
Fin Material Aluminium (Blue Coated) Aluminium (Blue Coated)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 23 × 17 1 × 24 × 19
Size (W × H × L) mm 25.4 × 483.0 × 553.4:573.4 12.7 × 504 × 830.2
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat – –
Protection Device – –
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation Range
Maximum °C (°F) 32 (89.6) 23 (73.4) 32 (89.6) 23 (73.4)
Minimum °C (°F) 16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
Outdoor Operation Range
Maximum °C (°F) 43 (109.4) 26 (78.8) 43 (109.4) 26 (78.8)
Minimum °C (°F) 16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
1. Cooling capacities are based on indoor temperature of 27°C DRY BULB (80.6°F DRY BULB), 19.0°C WET BULB (66°F WET BULB) and
outdoor air temperature of 35°C DRY BULB (95°F DRY BULB), 24°C WET BULB (75.2°F WET BULB)
