Panasonic CS-S18TKV Service Manual

7
Model
Indoor CS-S18TKV CS-S24TKV
Outdoor CU-S18TKV CU-S24TKV
Performance Test Condition JIS JIS
Power Supply
Phase, Hz Single, 60 Single, 60
V 220 220
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 1.10 5.20 6.00 1.12 6.00 7.10
BTU/h 3750 17700 20500 3820 20500 24200
kJ/h 3960 18720 21600 4030 21600 25560
Running Current A – 7.0 – – 7.7 –
Input Power W 290 1.48k 1.74k 320 1.65k 2.00k
EER
W/W 3.79 3.51 3.45 3.50 3.64 3.55
BTU/hW 12.93 11.96 11.78 11.94 12.42 12.10
kJ/hW 13.66 12.65 12.41 12.59 13.09 12.78
Power Factor % – 96 – – 97 –
Indoor Noise (H / L / QLo) dB-A 45 / 36 / 33 46 / 37 / 34
Outdoor Noise (H / L / QLo) dB-A 49 / – / – 49 / – / –
Max Current (A) / Max Input Power (W) 10.0 / 2.00k 11.5 / 2.45k
Starting Current (A) 7.0 7.7
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Output Power W 900 900
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG33 ASG33
Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles)
Input Power W 94.8 94.8
Output Power W 30 30
Speed
QLo rpm 760 780
Lo rpm 830 850
Me rpm 980 1010
Hi rpm 1140 1170
SHi rpm 1220 1270
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi rpm 900 820
Moisture Removal L/h (Pt/h) 2.9 (6.1) 3.3 (7.0)
Indoor Airflow
QLo m
3
/min (ft
3
/min) 12.7 (448) 13.1 (463)
Lo m
3
/min (ft
3
/min) 14.1 (498) 14.5 (512)
Me m
3
/min (ft
3
/min) 17.0 (600) 17.6 (621)
Hi m
3
/min (ft
3
/min) 19.3 (680) 20.3 (715)
SHi m
3
/min (ft
3
/min) 21.8 (770) 22.7 (802)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 36.0 (1270) 47.0 (1660)
Refrigeration
Cycle
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
FV50S (450) FV50S (450)
Refrigerant Type g (oz) R410A, 1.30k (45.9) R410A, 1.38k (48.7)
