8
Model
Indoor CS-S18TKV CS-S24TKV
Outdoor CU-S18TKV CU-S24TKV
Dimension
Height (I/D / O/D) mm (inch) 302 (11-29/32) 619 (24-3/8) 302 (11-29/32) 695 (27-3/8)
Width (I/D / O/D) mm (inch) 1120 (44-1/8) 824 (32-15/32) 1120 (44-1/8) 875 (34-15/32)
Depth (I/D / O/D) mm (inch) 236 (9-5/16) 299 (11-25/32) 236 (9-5/16) 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) 37 (82) 12 (26) 41 (90)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 15.88 (5/8)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 30 (98.4) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 20 (65.6) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 15 (0.2) 20 (0.2)
Length for Additional Gas m (ft) 10 (32.8) 10 (32.8)
Drain Hose
Inner Diameter mm 16.7 16.7
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coated) Aluminium (Pre Coated)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 17 × 17 2 × 17 × 17
Size (W × H × L) mm 836 × 315 × 25.4 836 × 315 × 25.4
Outdoor Heat
Exchanger
Fin Material Aluminium (Blue Coated) Aluminium (Blue Coated)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 28 × 19 2 × 31 × 17
Size (W × H × L) mm 25.4 × 588 × 865.3:845.4 25.4 × 651.0 × 866.6:846.6
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 15 20
Thermostat – –
Protection Device – –
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation Range
Maximum °C (°F) 32 (89.6) 23 (73.4) 32 (89.6) 23 (73.4)
Minimum °C (°F) 16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
Outdoor Operation Range
Maximum °C (°F) 43 (109.4) 26 (78.8) 43 (109.4) 26 (78.8)
Minimum °C (°F) 16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
1. Cooling capacities are based on indoor temperature of 27°C DRY BULB (80.6°F DRY BULB), 19.0°C WET BULB (66°F WET BULB) and
outdoor air temperature of 35°C DRY BULB (95°F DRY BULB), 24°C WET BULB (75.2°F WET BULB)
