Panasonic CS-S18TKV Service Manual

9
Model
Indoor CS-S28TKV
Outdoor CU-S28TKV
Performance Test Condition JIS
Power Supply
Phase, Hz Single, 60
V 220
Min. Mid. Max.
Cooling
Capacity
kW 1.15 7.80 8.40
BTU/h 3920 26600 28600
kJ/h 4140 28080 30240
Running Current A – 12.6 –
Input Power W 350 2.70k 2.95k
EER
W/W 3.29 2.89 2.85
BTU/hW 11.20 9.85 9.69
kJ/hW 11.83 10.40 10.25
Power Factor % – 97 –
Indoor Noise (H / L / QLo) dB-A 49 / 38 / 35
Outdoor Noise (H / L) dB-A 53 / - / -
Max Current (A) / Max Input Power (W) 14.6 / 3.26k
Starting Current (A) 12.6
Compressor
Type Hermetic Motor (Rotary)
Motor Type Brushless (4 poles)
Output Power W 1.70k
Indoor Fan
Type Cross-Flow Fan
Material ASG33
Motor Type DC (8-poles)
Input Power W 94.8
Output Power W 30
Speed
QLo rpm 800
Lo rpm 870
Me rpm 1070
Hi rpm 1270
SHi rpm 1350
Outdoor Fan
Type Propeller Fan
Material PP Resin
Motor Type AC / Induction (6-poles)
Input Power W –
Output Power W 62
Speed Hi rpm 650
Moisture Removal L/h (Pt/h) 4.6 (9.7)
Indoor Airflow
QLo m
3
/min (ft
3
/min) 13.3 (470)
Lo m
3
/min (ft
3
/min) 14.7 (519)
Me m
3
/min (ft
3
/min) 18.6 (657)
Hi m
3
/min (ft
3
/min) 21.7 (765)
SHi m
3
/min (ft
3
/min) 24.1 (851)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 51.8 (1830)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (800)
Refrigerant Type g (oz) R410A, 1.65k (58.2)
