Panasonic CS-S18TKV

146
 Piping Length Characteristic
o Room temperature: 27°C (DBT), 19°C (WBT)
o Outdoor temperature: 35°C (DBT), 24°C (WBT)
o Operation condition: High fan speed
o Compressor Frequency = Fc
13.800
13.900
14.000
14.100
14.200
14.300
3 4 5 6 7 8 9 10 11 12 13 14 15
Indoor Discharge
Air temperature (°C)
Piping Length (m)
220
3.100
3.200
3.300
3.400
3 4 5 6 7 8 9 101112131415
Cooling
Capacity (kW)
Piping Length (m)
4.040
4.060
4.080
4.100
4.120
3 4 5 6 7 8 9 101112131415
Current
(A)
Piping Length (m)
0.982
0.984
0.986
0.988
0.990
0.992
0.994
0.996
3 4 5 6 7 8 9 101112131415
Gas Side Piping
Pressure (MPa)
Piping Length (m)
