Panasonic CS-S18TKV Service Manual

63
11.2.4 Connect the Cable to the Indoor Unit
1 The inside and outside connection cable can be connected without removing the front grille.
2 Connection cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 4 ×
1.5 mm
2
flexible cord, type designation 245 IEC 57 or heavier cord.
3 Bind all the power supply cord lead wire with tape and route the power supply cord via the left escapement.
4 Remove the tapes and connect the connection cable between indoor unit and outdoor unit according to the
diagram below.
Note:
 Secure the connection cable onto the control board with the holder.
 Ensure the colour of wires of outdoor unit and the terminal Nos. are the same to the indoor’s respectively.
 Earth wire shall be Yellow/Green (Y/G) in colour and longer than other AC wires for safety reason.
•
How to pull the piping and drain hose out, in case of the
embedded piping.
•
In case of left piping how to insert the
connection cable and drain hose.
Rear view for left piping installation
Drain cap
Drain hose
PVC tube
for drain
hose
Indoor unit
72 mm
Piping
Cable
Apply putty or
caulking material
to seal the wall
opening.
Connection cable
Piping
M
o
r
e
t
h
a
n
4
7
0
m
m
M
o
r
e
t
h
a
n
1
1
5
0
m
m
PVC tube (VP-65) for piping
and connection cable
PVC tube for drain hose (VP-30)
PVC tube for drain
hose (VP-20)
More than 700 mm
Drain hose
from main unit
Replace the drain hose
(For the right piping, follow the same procedure)
Sleeve for piping hole
Drain hose
Piping
Connection cable
More than 1150 mm
Cable
4
5
°
Drain
hose
Piping
Adjust the piping
slightly downwards.
Drain hose
Connection cable
Recommended
length (mm)
Indoor & outdoor
Connection cable
Holder
Earth Wire
longer than
others
AC wires
for safety
reason
Terminal
Board
Outdoor unit
Tape
Connection cable
Indoor & outdoor
Connection cable
Escapement
Terminals on the indoor unit
Colour of wires
Terminals on the outdoor unit
12 3
12 3
Recommended
length (mm)
a b cd
35 35 35 55
WARNING
This equipment must be properly earthed.
