Panasonic CS-TZ9SKEW Service Manual

11
Model
Indoor CS-TZ9SKEW CS-TZ12SKEW
Outdoor CU-TZ9SKE CU-TZ12SKE
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Output Power W 500 700
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles)
Input Power W 47.3 47.3
Output Power W 40 40
Speed
QLo
Cool rpm 570 620
Heat rpm 710 800
Lo
Cool rpm 750 840
Heat rpm 780 1010
Me
Cool rpm 940 1050
Heat rpm 990 1150
Hi
Cool rpm 1140 1260
Heat rpm 1200 1300
SHi
Cool rpm 1190 1310
Heat rpm 1250 1350
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 830 830
Heat rpm 800 880
Moisture Removal L/h (Pt/h) 1.5 (3.2) 2.0 (4.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.25 (185) 5.16 (182)
Heat m
3
/min (ft
3
/min) 6.79 (240) 7.05 (249)
Lo
Cool m
3
/min (ft
3
/min) 7.23 (255) 7.47 (264)
Heat m
3
/min (ft
3
/min) 7.56 (267) 9.26 (327)
Me
Cool m
3
/min (ft
3
/min) 9.38 (331) 9.68 (342)
Heat m
3
/min (ft
3
/min) 9.87 (349) 10.78 (381)
Hi
Cool m
3
/min (ft
3
/min) 11.50 (405) 11.90 (420)
Heat m
3
/min (ft
3
/min) 12.20 (430) 12.30 (435)
SHi
Cool m
3
/min (ft
3
/min) 12.07 (426) 12.41 (438)
Heat m
3
/min (ft
3
/min) 12.73 (450) 12.83 (453)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 30.0 (1060) 28.70 (1015)
Heat m
3
/min (ft
3
/min) 28.9 (1020) 30.40 (1075)
Refrigeration
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm
3
FW50S (250) FW50S (320)
Refrigerant Type g (oz) R32, 670 (23.7) R32, 770 (27.2)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Charged Amount)
0.452 / 0.503 0.520 / 0.570
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32) 870 (34-9/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 204 (8-1/16) / 289 (11-13/32) 204 (8-1/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 27 (60) 9 (20) / 32 (71)
