Panasonic CS-TZ9SKEW Service Manual

23
6. Dimensions
6.1 Indoor Unit
6.1.1 CS-TZ9SKEW CS-TZ12SKEW CS-TZ15SKEW CS-TZ18SKEW
16.4
264.6
Unit: mm
B
A
C
PIPE
HOLE
CENTER
PIPE
HOLE
CENTER
128mm TO
PIPE HOLE
CENTER
128mm TO
PIPE HOLE
CENTER
496.6
128
241.5 241.5
128
Right
piping
hole
Left
piping
hole
Installation
plate
Indoor unit
external
dimensions
line
435435
43
95
<Top View>
<Front View>
<Bottom View>
<Rear View>
Relative position between the indoor unit and the installation plate <Front View>
<Side View> <Side View>
Gas side
Liquid side
Left piping
hole
Air outlet
direction
Air intake
direction
Left piping
hole
204
290
61.5
45
1-2 1-2
870
164
60
60
125
115
(41-61) 410
62
51
22
<Remote Control Holder>
<Remote Control>
134
47
