11.2 Outdoor Unit
11.2.1 CU-TZ9SKE
CN-HOT
CN-STM
CN-TH
CN-MTR1
CN-MTR2
CN-TANK
AC-BLK
DATA
AC-WHT
POWER
TRANSISTOR
(IPM)
CURRENT
TRANSFORMER
(CT)
