152
1.2 Heat Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Heat mode at 30°C
Voltage: 230V
1.2.1 CS-TZ9SKEW/CU-TZ9SKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 1817 960 2458 1057 2885 977 3082 801 3281 797
20 1820 908 2700 1050 2970 1000 3300 800 3413 797
16 1715 859 2785 1005 2989 952 3523 799 3617 796
1.2.2 CS-TZ12SKEW/CU-TZ12SKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 2501 1228 3004 1359 3594 1231 3623 1052 3857 1046
20 2505 1162 3300 1350 3700 1260 4000 1050 4013 1046
16 2361 1100 3403 1292 3724 1199 4142 1049 4253 1044
1.2.3 CS-TZ15SKEW/CU-TZ15SKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 2922 1522 3550 1711 4549 1768 4669 1352 4971 1345
20 2926 1440 3900 1700 4684 1810 5000 1350 5171 1345
16 2757 1363 4022 1627 4714 1723 5338 1349 5480 1342
1.2.4 CS-TZ18SKEW/CU-TZ18SKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 3195 1947 4251 2254 5275 2090 5416 1763 5766 1754
20 3200 1842 4670 2240 5430 2140 5800 1760 5998 1754
16 3016 1743 4816 2144 5465 2037 6192 1758 6357 1750
1.2.5 CS-TZ24SKEW/CU-TZ24SKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 4720 2218 5579 2767 6965 2705 8031 2614 8549 2601
20 4727 2099 6130 2750 7170 2770 8600 2610 8894 2600
16 4455 1987 6322 2633 7216 2636 9181 2607 9426 2595
TC - Total Cooling Capacity (W)
SHC - Sensible Heat Capacity (W)
IP - Input Power (W)
