20. Technical Data
Technical data provided are based on the air conditioner running under free frequency.
1.1 Cool Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Cool mode at 16°C
Voltage: 230V
1.1.1 CS-TZ9SKEW/CU-TZ9SKE
Indoor (°C) Outdoor DB (°C)
DB WB
-10 -7 0 5 16 25 35
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19 2646 2286 491 2658 2301 489 2669 2267 491 2593 2281 572 2919 2462 391 2721 2407 518 2500 2338 670
22 2919 1840 497 2872 1838 540 2886 1834 526 3002 1880 455 3215 2000 374 2982 1890 512 2659 1771 673
23
15.7 2363 2340 526 2381 2254 503 2357 2233 550 2372 2348 536 2630 2604 404 2439 2306 523 2158 2136 670
18.4 2613 1824 492 2631 1821 476 2649 1833 492 2550 1801 560 2795 1907 394 2661 1882 519 2392 1765 671
20
13.3 2099 2078 601 2080 2059 503 2245 2219 526 2178 2141 549 2474 2449 412 2247 2224 525 2004 1984 669
15.8 2384 1800 525 2378 1797 498 2364 1774 552 2318 1749 577 2601 1896 403 2423 1824 523 2174 1714 671
(Dry bulb value based on 46% humidity)
1.1.2 CS-TZ12SKEW/CU-TZ12SKE
Indoor (°C) Outdoor DB (°C)
DB WB
-10 -7 0 5 16 25 35
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19 3821 2960 733 3839 2979 729 3854 2935 733 3745 2953 854 4215 3188 583 3930 3116 774 3500 2934 1000
22 4215 2382 742 4148 2379 807 4168 2374 784 4335 2434 680 4643 2589 558 4306 2447 764 3840 2293 1004
23
15.7 3413 3379 785 3438 2918 750 3404 2891 821 3425 3391 801 3798 3760 602 3523 2986 781 3116 2860 1000
18.4 3774 2362 734 3800 2358 710 3826 2373 734 3682 2332 836 4037 2469 588 3843 2436 775 3454 2285 1001
20
13.3 3031 3001 898 3004 2705 750 3242 2872 785 3146 2772 820 3573 3537 616 3245 2912 784 2895 2728 998
15.8 3443 2331 784 3434 2326 743 3414 2297 824 3348 2265 861 3757 2455 601 3500 2361 780 3140 2219 1001
(Dry bulb value based on 46% humidity)
1.1.3 CS-TZ15SKEW/CU-TZ15SKE
Indoor (°C) Outdoor DB (°C)
DB WB
-10 -7 0 5 16 25 35
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19 4445 3389 924 4466 3410 919 4484 3360 924 4356 3380 1076 4904 3649 735 4572 3567 975 4200 3465 1260
22 4903 2727 935 4825 2724 1016 4848 2718 988 5043 2787 857 5401 2964 703 5009 2801 963 4467 2626 1265
23
15.7 3970 3931 989 4000 3341 945 3960 3309 1034 3984 3944 1009 4418 4374 759 4098 3418 984 3625 3274 1260
18.4 4390 2704 924 4421 2699 894 4451 2717 925 4283 2669 1054 4696 2826 740 4470 2789 976 4018 2616 1261
20
13.3 3526 3491 1131 3494 3097 946 3772 3288 990 3660 3173 1033 4156 4115 776 3774 3334 988 3367 3123 1257
15.8 4005 2668 987 3995 2663 936 3971 2630 1039 3895 2593 1085 4370 2810 757 4071 2703 983 3652 2541 1261
(Dry bulb value based on 46% humidity)
