Panasonic CS-TZ9SKEW Service Manual

10
3. Specifications
Model
Indoor CS-TZ9SKEW CS-TZ12SKEW
Outdoor CU-TZ9SKE CU-TZ12SKE
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 2.50 3.00 0.85 3.50 3.90
BTU/h 2900 8530 10200 2900 11900 13300
Kcal/h 730 2150 2580 730 3010 3350
Running Current A – 3.00 – – 4.40 –
Input Power W 250 670 890 255 1.00k 1.19k
Annual Consumption kWh – 335 – – 500 –
EER
W/W 3.40 3.73 3.37 3.33 3.50 3.28
BTU/hW 11.60 12.73 11.46 11.37 11.90 11.18
Kcal/hW 2.92 3.21 3.90 2.86 3.01 2.82
ErP
Pdesign kW 2.5 3.5
SEER (W/W) 6.2 6.2
Annual
Consumption
kWh 141 198
Class A++ A++
Power Factor % – 97 – – 99 –
Indoor Noise (H / L / QLo)
dB-A 40 / 26 / 20 42 / 30 / 20
Power Level dB 56 / – 58 / –
Outdoor Noise (H / L)
dB-A 47 / – 48 / –
Power Level dB 62 / – 63 / –
Heating
Capacity
kW 0.80 3.30 4.10 0.80 4.00 5.10
BTU/h 2730 11300 14000 2730 13600 17400
Kcal/h 690 2840 3530 690 3440 4390
Running Current A – 3.60 – – 4.60 –
Input Power W 195 800 1.13k 200 1.05k 1.42k
COP
W/W 4.10 4.13 3.63 4.00 3.81 3.59
BTU/hW 14.00 14.13 12.39 13.65 12.95 12.25
Kcal/hW 3.54 3.55 3.12 3.45 3.28 3.09
ErP
Pdesign kW 2.4 2.8
Tbivalent °C -10 -10
SCOP (W/W) 4.2 4.2
Annual
Consumption
kWh 800 933
Class A+ A+
Power Factor % – 97 – – 99 –
Indoor Noise (H / L / QLo)
dB-A 40 / 27 / 24 42 / 33 / 25
Power Level dB 56 / – 58 / –
Outdoor Noise (H / L)
dB-A 48 / – 50 / –
Power Level dB 63 / – 65 / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 2.97 / 1.00k / 2.97 3.70 / 1.26k / 2.94
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 2.70 / 1.05k / 2.57 3.30 / 1.35k / 2.44
Max Current (A) / Max Input Power (W) 4.9 / 1.13k 6.2 / 1.42k
Starting Current (A) 3.60 4.60
