145
19.2.1.4 To Remove Control Board
Figure 6
19.2.1.5 To Remove Cross Flow Fan and Indoor Fan Motor
Figure 7
15. Remove the bearing by pulling it
out gently.
14. Remove the screw from the
evaporator.
Holdfast
Figure 8
