168
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-TZ15SKEW CS-TZ18SKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C00200 ←
2 FAN MOTOR 1 L6CBYYYL0037 ←
O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ←
4 BEARING ASSY 1 CWH64K1010 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 PARTICULAR PIECE 1 CWD933067B ←
7 EVAPORATOR 1 CWB30C4660 ACXB30C01130
8 FLARE NUT (LIQUID) 1 CWT251030 ←
9 FLARE NUT (GAS) 1 CWT251032 ←
10 CONTROL BOARD CASING 1 ACXH10-00510 ←
11 PARTICULAR PIECE 1 CWD933137 ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2357 ←
O
13 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C06060 ACXA73C06070 O
15 ELECTRONIC CONTROLLER - INDICATOR 1 CWA745300 ←
O
18 INDICATOR HOLDER 1 CWD933021 ←
19 SENSOR COMPLETE 1 CWA50C2664 ← O
20 DISCHARGE GRILLE COMPLETE 1 ACXE20C00240 ←
21 BACK COVER CHASSIS 1 CWD933233C ←
22 FULCRUM 1 CWH621102 ←
23 VERTICAL VANE 11 CWE241350 ←
24 CONNECTING BAR 1 CWE261152 ←
25 CONNECTING BAR 1 CWE261153 ←
26 CONNECTING BAR 1 CWE261154 ←
27 CONNECTING BAR 1 CWE261155 ←
28 AIR SWING MOTOR 1 CWA981264 ←
O
29 CAP - DRAIN TRAY 1 CWH521259 ←
30 HORIZONTAL VANE COMPLETE 1 CWE24C1268 ←
31 CONTROL BOARD COVER - COMPLETE 1 CWH13C1183 ←
32 REMOTE CONTROL COMPLETE 1 ACXA75C00450 ← O
33 FRONT GRILLE COMPLETE 1 ACXE10C01030 ACXE10C01050 O
34 INTAKE GRILLE COMPLETE 1 ACXE22C00260 ←
35 GRILLE DOOR COMPLETE 1 CWE14C1090 ←
36 AIR FILTER 2 CWD001279 ← O
37 SCREW - FRONT GRILLE 3 XTT4+16CFJ ←
38 CAP - FRONT GRILLE 2 CWH521194 ←
39 DRAIN HOSE 1 CWH851173 ←
40 INSTALLATION PLATE 1 CWH361147 ←
41 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
42 AIR PURIFYING FILTER 1 CWD00C1291 ←
(NOTE)
 All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
 “O” marked parts are recommended to be kept in stock.
