Panasonic CS-VU18SKQ Service Manual

129
 Piping Length Characteristic
o Room temperature: 27°C (DBT), 19°C (WBT)
o Operation condition: High fan speed
o Outdoor temperature: 35°C (DBT), 24°C (WBT)
o Compressor Frequency = Fc
Piping Length (m)
Current
(A)
Piping Length (m)
Gas Side Piping
Pressure (MPa)
Piping Length (m)
Outlet Air
Tempeature (°C)
Piping Length (m)
Cooling
Capacity (kW)
220V 230V
220V 230V
220V 230V
220V 230V
6.000
6.220
6.440
6.660
6.880
7.100
3 4 5 6 7 8 9 101112131415161718192021222324252627282930
0.880
0.890
0.900
0.910
0.920
0.930
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
14.500
14.720
14.940
15.160
15.380
15.600
3 4 5 6 7 8 9 10 11121314 1516 1718 192021222324252627282930
4.900
4.980
5.060
5.140
5.220
5.300
3 4 5 6 7 8 9 101112131415 16171819 20212223 24252627 282930
