17
5. Dimensions
5.1 Indoor Unit
Relative position between the indoor unit and the installation plate <Front View>
Left
piping
hole
Right
piping
hole
Indoor unit
external
dimensions
line
Installation
plate
Unit : mm
13.5
264
80
127
741
424 448
151
80
128
256
306
<Top View>
<Front View>
<Bottom View>
<Rear View>
<Side View><Side View>
<Remote Control Holder>
<Remote Control>
59
16569
64
950
355 (41-61)
Left piping
hole
Air outlet
direction
Air inlet
direction
Air inlet
direction
280
318
42
60
Right piping
hole
Gas side
Liquid side
iCOMFORT
TEMP
TEMP
SHOWER /
DIRECT
OFF/ON
