10.2 Outdoor Unit
10.2.1 Main Printed Circuit Board
10.2.1.1 CU-VU9SKQ CU-VU12SKQ
CN-TH
CN-TANK
CN-S
AC-WHT
AC-BLK
DATA
POWER
TRANSISTOR
(IPM)
CURRENT
TRANSFORMER
(CT)
