13. Operation Control
13.1 Basic Function
Inverter control, which equipped with a microcomputer in determining the most suitable operation mode as time
passes, automatically adjusts output power for maximum comfort always. In order to achieve the suitable operation
mode, the microcomputer maintains the set temperature by measuring the temperature of the environment and
performing temperature shifting. The compressor at outdoor unit is operating following the frequency instructed by
the microcomputer at indoor unit that judging the condition according to internal setting temperature and intake air
temperature.
13.1.1 Internal Setting Temperature
Once the operation starts, remote control setting temperature will be taken as base value for temperature shifting
processes. These shifting processes are depending on the air conditioner settings and the operation environment.
The final shifted value will be used as internal setting temperature and it is updated continuously whenever the
electrical power is supplied to the unit.
13.1.2 Cooling Operation
13.1.2.1 Thermostat Control
 Compressor is OFF when intake Air Temperature - Internal Setting Temperature < -1.5°C.
 Compressor is ON after waiting for 3 minutes, if the Intake Temperature - Internal Setting Temperature >
Compressor OFF point.
13.1.3 Soft Dry Operation
13.1.3.1 Thermostat Control
 Compressor is OFF when Intake Temperature - Internal Setting Temperature < -2.0°C.
 Compressor is ON after waiting for 3 minutes, if the Intake Air Temperature - Internal Setting Temperature >
Compressor OFF point.
13.1.3.2 iCOMFORT Operation
 iCOMFORT operation can be set using remote control.
 This operation is applied to faster cool down time of the room and comfort feel by thermal shift and fan speed
control.
 Thermal control
o The internal setting temperature will shift 1°C lower than remote control setting temperature for maximum
4 hours to provide extra cool and better comfort. After max. 4 hours, the set temperature follow the last set
temperature setting.
 Fan speed control
o Fan speed selection is prohibited. Fan speed display at remote control is fixed at AUTO FAN.
o The internal fan speed will set to be SHi + iCOMFORT fan speed shift, it is slightly higher than SHi fan speed
initially for maximum 30 minutes to achieve the setting temperature quickly. Then it will shift between SHi ~
Lo fan speed depends on intake and setting temperature.
 Vane control is follow remote control setting. Except for Auto horizontal vane, the horizontal vane is fixed at the
lower position and shift to the upper position after reaches set temperature.
Remote Control Setting Temperature
16°C ~ 30°C
Indoor Air Temperature Shifting
Outdoor Air Temperature Shifting
Setting Temperature Limit Checking
(Min: 16°C; Max: 33°C)
Internal Setting Temperature
