29
10. Printed Circuit Board
10.1 Indoor Unit
10.1.1 Main Printed Circuit Board
CN-DUST
CN-STM1
CN-STM4
CN-RMT
CN-STM6
CN-DISP
CN-SW
CN-TH1
CN-FM
CN-CLN
CN-RCV
CN-STM3
CN-TH2
AC303
CN-STM5
JP1 (Random Auto Restart enable/disable)
