Model
Indoor CS-VU18SKQ
Outdoor CU-VU18SKQ
Performance Test Condition JIS
Power Supply
Phase, Hz Single, 60
V 220 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 1.10 5.20 5.80 1.10 5.20 5.80
BTU/h 3750 17700 19800 3750 17700 19800
kJ/h 3960 18720 20880 3960 18720 20880
Running Current A - 7.0 - - 6.7 -
Input Power W 290 1.45k 1.67k 290 1.45k 1.67k
EER
W/W 3.79 3.59 3.47 3.79 3.59 3.47
BTU/hW 12.93 12.21 11.86 12.93 12.21 11.86
kJ/hW 13.66 12.91 12.50 13.66 12.91 12.50
Power Factor % - 94 - - 94 -
Indoor Noise (H / L / QLo) dB-A 46 / 36 / 33 46 / 36 / 33
Outdoor Noise (H / L / QLo) dB-A 49 / - / - 49 / - / -
Max Current (A) / Max Input Power (W) 10.0 / 2.15k
Starting Current (A) 7.0
Compressor
Type Hermetic Motor
Motor Type Brushless (6 poles)
Output Power W 900
Indoor Fan
Type Cross-Flow Fan
Material ASG20K1
Motor Type DC / Transistor (8 poles)
Input Power W 94.8 - 94.8
Output Power W 30
Speed
QLo rpm 1020
Lo rpm 1110
Me rpm 1400
Hi rpm 1690
SHi rpm 1810
Outdoor Fan
Type Propeller
Material PP
Motor Type AC / Induction (6 poles)
Input Power W -
Output Power W 40
Speed Hi rpm 900
Moisture Removal L/h (Pt/h) 2.9 (6.1)
Indoor
Airflow
QLo m
3
/min (ft
3
/m) 9.40 (332)
Lo m
3
/min (ft
3
/m) 10.20 (360)
Me m
3
/min (ft
3
/m) 12.00 (424)
Hi m
3
/min (ft
3
/m) 13.40 (475)
SHi m
3
/min (ft
3
/m) 15.20 (537)
Outdoor
Airflow
Hi m
3
/min (ft
3
/m) 34.90 (1230)
