Panasonic CS-Z25UFRAW Service Manual

13
Indoor
Model CS-Z35UFRAW
POS (EAN) 5025232885442
Outdoor
Model CU-Z35UBRA
POS (EAN) 5025232885473
Performance Test Condition AS
Power Supply
Phase, Hz Single, 50
V 230 240
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 3.50 3.80 0.85 3.50 3.80
BTU/h 2900 11900 13000 2900 11900 13000
kcal/h 730 3010 3270 730 3010 3270
Running Current A – 3.90 – – 3.70 –
Input Power W 240 860 1.02k 240 860 1.02k
EER / EER CLASS W/W 3.54 4.07 / 3.5 3.73 3.54 4.07 / 3.5 3.73
EER
BTU/hW 12.08 13.84 12.75 12.08 13.84 12.75
kcal/hW 3.04 3.50 3.21 3.04 3.50 3.21
Power Factor % – 96 – – 97 –
Indoor Noise (H / L / QLo)
dB-A 39 / 26 / 20
Power Level dB 55 / 42 / 36
Outdoor Noise (H / L / QLo)
dB-A 48 / – / –
Power Level dB 63 / – / –
Heating
Capacity
kW 0.85 4.30 6.00 0.85 4.30 6.00
BTU/h 2900 14700 20500 2900 14700 20500
kcal/h 730 3700 5160 730 3700 5160
Running Current A – 4.80 – – 4.60 –
Input Power W 240 1.06k 1.75k 240 1.06k 1.75k
COP / COP CLASS W/W 3.54 4.06 / 3.5 3.43 3.54 4.06 / 3.5 3.43
COP
BTU/hW 12.08 13.87 11.71 12.08 13.87 11.71
kcal/hW 3.04 3.49 2.95 3.04 3.49 2.95
Power Factor % – 96 – – 96 –
Indoor Noise (H / L / QLo)
dB-A 39 / 25 / 19
Power Level dB 55 / 41 / 35
Outdoor Noise (H / L / QLo)
dB-A 50 / – / –
Power Level dB 65 / – / –
H2
Capacity kW 3.70
Input Power kW 1.20
COP W/W 3.08
Powerful
Heat
Capacity kW 6.00
Input Power kW 1.75
COP W/W 3.43
Max Current (A) / Max Input Power (W) 8.0 / 1.75k
Starting Current (A) 4.80
Compressor
Type Hermetic Motor (Rotary)
Motor Type Brushless (6 poles)
Output Power W 700
