Panasonic CS-Z25UFRAW Service Manual

14
Indoor
Model CS-Z35UFRAW
POS (EAN) 5025232885442
Outdoor
Model CU-Z35UBRA
POS (EAN) 5025232885473
Indoor Fan
Type Cross Flow Fan
Material ASG33
Motor Type DC / Transistor (8-poles)
Input Power W 44
Output Power W 30
Speed
QLo
Cool rpm 520
Heat rpm 520
Lo
Cool rpm 630
Heat rpm 640
Me
Cool rpm 850
Heat rpm 920
Hi
Cool rpm 1080
Heat rpm 1190
SHi
Cool rpm 1130
Heat rpm 1240
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 850
Heat rpm 790
Moisture Removal L/h (Pt/h) 2.0 (4.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min.) 5.0 (177)
Heat m
3
/min (ft
3
/min.) 5.0 (177)
Lo
Cool m
3
/min (ft
3
/min.) 6.0 (212)
Heat m
3
/min (ft
3
/min.) 6.1 (215)
Me
Cool m
3
/min (ft
3
/min.) 8.1 (285)
Heat m
3
/min (ft
3
/min.) 8.7 (305)
Hi
Cool m
3
/min (ft
3
/min.) (L/S) 10.2 (360) (170)
Heat m
3
/min (ft
3
/min.) (L/S) 10.9 (385) (182)
SHi
Cool m
3
/min (ft
3
/min.) 10.7 (375)
Heat m
3
/min (ft
3
/min.) 11.7 (410)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min.) 34.3 (1210)
Heat m
3
/min (ft
3
/min.) 31.8 (1125)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FW50S (320)
Refrigerant Type g (oz) R32, 970 (34.2)
Dimension
Unit
Height (I/D / O/D) mm (inch) 600 (23-5/8) / 619 (24-3/8)
Width (I/D / O/D) mm (inch) 750 (29-17/32) / 824 (32-15/32)
Depth (I/D / O/D) mm (inch) 207 (8-5/32) / 299 (11-25/32)
Pckg.
(Stacking
Condition)
Height (I/D / O/D) mm (inch) 281 (11-3/32) / 680 (26-25/32)
Width (I/D / O/D) mm (inch) 830 (32-11/16) / 958 (37-23/32)
Depth (I/D / O/D) mm (inch) 676 (26-5/8) / 416 (16-13/32)
Weight
Net (I/D / O/D) kg (lb) 13 (29) / 35 (77)
Gross (I/D / O/D) kg (lb) 15 (33) / 38 (84)
