REPLACEMENT PARTS LIST
Model: CT-27DC50B
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
- 37 -
228-00
PARTS LIST
Parts List
REF NO. PART NO. DESCRIPTION
CAPRISTORS
CRA801 EXNG131P365 RES-CAP 130PF/3.6 MEG
CRA802 EXNG131P365 RES-CAP 130PF/3.6 MEG
CRA851 EXNG131P365 RES-CAP 130PF/3.6 MEG
CAPACITORS
C001 ECA1CM101 CAP,E 100UF/16V
C002 ECJ2VB1H102K CAP,C .001UF-K-50V
C003 ECA1HM220 CAP,E 22UF/50V
C005 ECA1CM331 CAP,E 330UF/16V
C006 ECJ2VB1H102K CAP,C .001UF-K-50V
C008 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C010 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C011 ECA1CM221 CAP,E 220UF/16V
C013 ECA1CM101 CAP,E 100UF/16V
C016 ECJ2VC1H101J CAP,C 100PF-J-50V
C017 ECJ2VC1H220J CAP,C 22PF-J-50V
C018 ECJ2VC1H220J CAP,C 22PF-J-50V
C019 ECA1CM101 CAP,E 100UF/16V
C020 ECA1CM471 CAP,E 470UF/16V
C021 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C022 ECA1CHG471B CAP,E 470UF-16V
C024 ECA1HM4R7 CAP,E 4.7UF/50V
C025 ECJ2VC1H101J CAP,C 100PF-J-50V
C026 ECA1HM010 CAP,E 1.0UF/50V
C029 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C031 ECJ2VB1H821K CAP,C 820PF-K-50V
C032 ECA1CM470 CAP,E 47UF/16V
C033 ECJ2VC1H680J CAP,C 68PF-J-50V
C034 ECJ2VC1H680J CAP,C 68PF-J-50V
C036 ECJ2VC1H220J CAP,C 22PF-J-50V
C037 ECJ2VC1H220J CAP,C 22PF-J-50V
C038 ECJ2VC1H220J CAP,C 22PF-J-50V
C040 ECA1EHG470B CAP,E 47UF-25V
C041 ECJ2VC1H330J CAP,C 33PF-J-50V
C101 ECJ2VF1H223Z CAP,C .022UF-Z050V
C102 ECA1CM101 CAP,E 100UF/16V
C103 ECJ2VC1H300J CAP,C 30PF-J-50V
C105 ECJ2VC1H221J CAP,C 220PF-J-50V
C106 ECA1HMR47 CAP,E .47UF/50V
C107 ECJ2VC1H390J CAP,C 39PF-J-50V
C108 ECA1HMR22 CAP,E .22UF/50V
C110 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C111 ECA1HM100 CAP,E 10UF/50V
C113 ECA1HM100 CAP,E 10UF/50V
C114 ECJ2VC1H120J CAP,C 12PF-J-50V
C151 ECA1HMR22 CAP,E .22UF/50V
C201 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C202 ECJ2VC1H101J CAP,C 100PF-J-50V
C203 ECA1HM4R7 CAP,E 4.7UF/50V
C301 ECJ2VC1H390J CAP,C 39PF-J-50V
C302 EEANA1E1R0B CAP,E 1.0UF-25V
C304 ECEA1HNR47U CAP,E .47UF-50V
C305 ECA1HM4R7 CAP,E 4.7UF/50V
C306 ECA1CM221 CAP,E 220UF/16V
C308 ECQB1H823JM CAP,P .082UF-J-50V
C309 ECA1CM101 CAP,E 100UF/16V
C310 ECA1HM4R7 CAP,E 4.7UF/50V
C311 ECA1HM4R7 CAP,E 4.7UF/50V
C312 ECA1HM220 CAP,E 22UF/50V
C351 TACCW331T50V CAP,C 330PF/50V
C352 TACCW331T50V CAP,C 330PF/50V
C353 TACCW331T50V CAP,C 330PF/50V
C354 ECKD3D102KB CAP,C .001UF-K-2KV
C357 EEANA1E1R0B CAP,E 1.0UF-25V
C401 ECQB1H153JM CAP,P .015UF-J-50V
C402 ECJ2VC1H471J CAP,C 470PF-J-50V
C403 ECA1HM2R2 CAP,E 2.2UF/50V
C451 ECA1CHG470B CAP,E 47UF-16V
C452 ECSF1EE105 CAP,T 1.0UF/25V
C453 ECA1HHG010B CAP,E 1UF-50V
C454 ECA1EM102 CAP,E 1000UF/25V
C455 ECA1VHG101B CAP,E 100UF-35V
C456 ECQB1H103JM CAP,P .01UF-J-50V
C459 ECA1VHG471B CAP,E 470UF-35V
C460 ECQM1104JZ CAP,P .1UF-J-100V
C462 ECA1HM100 CAP,E 10UF/50V
C502 ECQB1H223JM CAP,P .022UF-J-50V
C503 ECA1HM2R2 CAP,E 2.2UF/50V
C504 ECJ2VC1H221J CAP,C 220PF-J-50V
C505 ECJ2VU1H221J CAP,C 220PF-J-50V
C506 ECA1CM221 CAP,E 220UF/16V
C508 ECJ2VC1H331J CAP,C 330PF-J-50V
C510 ECCD2H100D CAP,C 10PF-D-500V
C511 ECKD2H821KB CAP,C 820PF-K-500V
C512 ECKD2H101KB CAP,C 100PF-K-500V
C531 ECA1HM220 CAP,E 22UF/50V
C532 ECA1CM102 CAP,E 1000UF/16V
C534 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C551 ECA1VM331 CAP,E 330UF/35V
C552 ECA1CM331 CAP,E 330UF/16V
C553 ECA1CM331 CAP,E 330UF/16V
C554 ECKD2H561KB CAP,C 560PF-K-500V
C555 ECA2EM220 CAP,E 22UF-250V
C556 ECA1CM102 CAP,E 1000UF/16V
C557 ECKD2H102KB CAP,C .001UF-K-500V
C558 ECA1CM221 CAP,E 220UF/16V
C560 ECEA1HN2R2U CAP,E 2.2UF/50V
C561 ECKD2H561KB CAP,C 560PF-K-500V
C562 ECKD2H561KB CAP,C 560PF-K-500V
C563 ECWH16822JVB CAP,P 8200PF-J-1.5KV
