- 38 -
Parts List
REPLACEMENT PARTS LIST
Model: CT-27DC50B
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
228-00
PARTS LIST
C564 ECWH16272JVY CAP,P 2700PF-J-1.5KV
C565 ECKD3D561JB CAP,C 560PF-J-2KV
C566 ECKD3D181JB CAP,C 180PF-J-2KV
C568 ECQM2274JZ CAP,P .27UF-J-200V
C569 ECWF2474JSR CAP,P .47UF-J-200V
C571 ECA1CHG471B CAP,E 470UF-16V
C572 ECA1HM100 CAP,E 10UF/50V
C573 ECA1CM101 CAP,E 100UF/16V
C601 ECJ2VB1H102K CAP,C .001UF-K-50V
C604 ECJ2VU1H150J CAP,C 15PF-J-50V
C605 ECJ2VB1H332K CAP,C .0033UF-K-50V
C606 ECA1HM010 CAP,E 1.0UF/50V
C801 ECKDAE472ZED CAP,C .4700PF-Z-250VAC
C802 ECKDAE472ZED CAP,C .4700PF-Z-250VAC
C803 ECKDAE472ZED CAP,C .4700PF-Z-250VAC
C804 ECKDAE472ZED CAP,C .4700PF-Z-250VAC
C805 EC0S2DA221BB CAP,E 220UF/200V
C806 EC0S2DA221BB CAP,E 220UF/200V
C807 ECA1HM2R2 CAP,E 2.2UF/50V
C808 ECA1CM101 CAP,E 100UF/16V
C809 EC0S2DG151DG CAP,E 151UF/200V
C810 ECQU2A103MV CAP,P .01UF-M-250VAC
C811 ECQU2A103MV CAP,P .01UF-M-250VAC
C812 ECQU2A224MV CAP,P .22UF-M-250VAC
C814 ECQB1H823JM CAP,P .082UF-J-50V
C815 ECA1EHG101B CAP,E 100UF-25V
C818 ECKD3A821KB CAP,C 820PF-K-1KVDC
C820 ECA1JHG100B CAP,E 10UF-63V
C821 ECKD2H561KB CAP,C 560PF-K-500V
C822 ECA1VHG221B CAP,E 220UF-35V
C823 ECA160V33UE CAP,E 33UF/160V
C824 ECKD3A331KB CAP,C 330PF-K-1KV
C825 ECKD3A471KB CAP,C 470PF-K-1KV
C853 TACA5102G125 CAP, C
C855 TACA5222G125 CAP, C
C859 ECA2DHG101E CAP,E 100UF-200V
C861 ECKD3A471KB CAP,C 470PF-K-1KV
C862 ECKD3A182KB CAP,C .0018UF-K-1KV
C864 ECQB1H223JF CAP,P .022UF-J-50V
C866 ECQB1H104JF CAP,P .1UF-J-50V
C867 ECQB1H683JF CAP,P .068UF-J-50V
C868 ECQB1H104JF CAP,P .1UF-J-50V
C871 ECA1EHG470B CAP,E 47UF-25V
C881 ECQV1H104JL CAP,P .10UF-J-50V
C882 ECQB1H223JF CAP,P .022UF-J-50V
C883 EEUFC1A102B CAP,E 1000UF-10V
C884 ECA1AHG102B CAP,E 1000UF-10V
C885 ECFR1E104KR2 CAP,C .10UF-25V
C886 ECA1CHG221B CAP,E 220UF/16V
C887 ECA0JM102 CAP,E 1000UF/6.3V
REF NO. PART NO. DESCRIPTION
C888 EEUFC1A331B CAP,E 330UF-10V
C889 ECA1AHG102B CAP,E 1000UF-10V
C891 ECA0JM102 CAP,E 1000UF/6.3V
C892 EEUFC1V151B CAP,E 150UF
C893 ECA1HHG330B CAP,E 33UF/50V
C894 EEUFC1V151B CAPACITOR
C895 ECA1HHG330B CAP,E 33UF/50V
C896 EEUFC1E331B CAPACITOR
C897 ECA1EHG221B CAP,E 220UF-25V
C898 ECA1CHG221B CAP,E 220UF/16V
C2201 ECA1HM4R7 CAP,E 4.7UF/50V
C2202 ECA1HM2R2 CAP,E 2.2UF/50V
C2203 ECA1HM4R7 CAP,E 4.7UF/50V
C2204 ECSF16E10VB CAP,T 1UF-16V
C2205 ECA1HM010 CAP,E 1.0UF/50V
C2206 ECQB1H223JM CAP,P .022UF-J-50V
C2207 ECSF16E3R3 CAP,T 3.3UF/16V
C2208 ECJ2VB1C104K CAP,C .1UF-I-16V
C2209 ECJ2VB1C104K CAP,C .1UF-I-16V
C2210 ECJ2VB1C104K CAP,C .1UF-I-16V
C2212 ECQB1H473JM CAP,P .047UF-J-50V
C2215 ECA1CM101 CAP,E 100UF/16V
C2218 ECA1HMR47 CAP,E .47UF/50V
C2220 EEANA1E100B CAP,E 10UF-25V
C2301 ECA1VM102 CAP,E 1000UF/35V
C2302 ECA1HM010 CAP,E 1.0UF/50V
C2305 ECA1HM010 CAP,E 1.0UF/50V
C2306 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C2307 ECA1CM102 CAP,E 1000UF/16V
C2308 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C2309 ECQB1H473JM CAP,P .047UF-J-50V
C2311 ECA1HM3R3 CAP,E 3.3UF/50V
C2313 ECA1VM101 CAP,E 100UF/35V
C2314 ECQB1H473JM CAP,P .047UF-J-50V
C2315 ECA1HM100 CAP,E 10UF/50V
C2321 ECA1HM100 CAP,E 10UF/50V
C2324 ECA1HM100 CAP,E 10UF/50V
C2325 ECA1CM102 CAP,E 1000UF/16V
C2326 ECJ2VB1H223K CAP,C .022UF-K-50V
C2327 ECJ2VB1H223K CAP,C .022UF-K-50V
C2328 ECJ2VB1H223K CAP,C .022UF-K-50V
C2329 ECJ2VB1H223K CAP,C .022UF-K-50V
C2331 EEANA1E100B CAP,E 10UF-25V
C2332 EEANA1E100B CAP,E 10UF-25V
C2333 ECA1HM0R1 CAP,E 0.1UF/50V
C2334 ECJ2VB1H472K CAP,C .0047UF-K-50V
C2335 ECA1VM470 CAP,E 47UF/35V
C2336 ECQB1H104JM CAP,P .1UF-J-50V
C2337 ECA1HM0R1 CAP,E 0.1UF/50V
C2338 ECA1HM4R7 CAP,E 4.7UF/50V
REF NO. PART NO. DESCRIPTION
