REPLACEMENT PARTS LIST
Model: CT-27DC50B
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
- 39 -
228-00
PARTS LIST
Parts List
C2339 ECA1HM100 CAP,E 10UF/50V
C2340 ECA1HMR47 CAP,E .47UF/50V
C2341 ECA1HM4R7 CAP,E 4.7UF/50V
C2342 ECA1HM4R7 CAP,E 4.7UF/50V
C2343 ECA1HM4R7 CAP,E 4.7UF/50V
C2344 ECJ2VB1H472K CAP,C .0047UF-K-50V
C2345 ECA1HM0R1 CAP,E 0.1UF/50V
C2346 ECA1VM470 CAP,E 47UF/35V
C2347 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C2351 ECA1HM010 CAP,E 1.0UF/50V
C2353 ECA1HM010 CAP,E 1.0UF/50V
C2359 ECA1HM010 CAP,E 1.0UF/50V
C2360 ECA1HM010 CAP,E 1.0UF/50V
C2362 ECA1VM470 CAP,E 47UF/35V
C3011 ECA1HM010 CAP,E 1.0UF/50V
C3012 ECA1HM010 CAP,E 1.0UF/50V
C3013 ECA1HM100 CAP,E 10UF/50V
C3014 ECA1HM100 CAP,E 10UF/50V
C3018 ECA1HM010 CAP,E 1.0UF/50V
C3019 ECA1HM010 CAP,E 1.0UF/50V
C3025 ECA1HM100 CAP,E 10UF/50V
C3234 ECA1VM470 CAP,E 47UF/35V
C3235 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3236 ECA1CM221 CAP,E 220UF/16V
C3237 ECA1CM221 CAP,E 220UF/16V
C3240 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3331 ECA1CM101 CAP,E 100UF/16V
C3332 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3501 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3503 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3505 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3506 ECA1CM221 CAP,E 220UF/16V
C3601 ECA1VM221 CAP,E 220UF/35V
C3602 ECA1CM470 CAP,E 47UF/16V
C3603 ECA1CM470 CAP,E 47UF/16V
C3604 ECA1CM221 CAP,E 220UF/16V
C3605 ECA1CM221 CAP,E 220UF/16V
C3606 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C3607 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C3608 ECJ2VC1H101J CAP,C 100PF-J-50V
C3609 ECJ2VC1H101J CAP,C 100PF-J-50V
C3610 ECJ2VC1H102J CAP,C .001UF-J-50V
C3611 ECJ2VC1H102J CAP,C .001UF-J-50V
C3614 ECA1HM100 CAP,E 10UF/50V
C3615 ECA1HM100 CAP,E 10UF/50V
C3616 ECJ2VC1H102J CAP,C .001UF-J-50V
C3617 ECJ2VC1H102J CAP,C .001UF-J-50V
C3619 ECA1CM221 CAP,E 220UF/16V
C3620 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3621 ECJ2VB1H471K CAP,C 470PF-K-50V
REF NO. PART NO. DESCRIPTION
C3622 ECJ2VB1H103K CAP,C .01UF-K-50V
C3623 EEUFC1C471B CAP,E 470UF-16V
C3624 ECA0JM102 CAP,E 1000UF/6.3V
C3625 ECA0JM102 CAP,E 1000UF/6.3V
C3626 ECJ2VB1H331K CAP,C 330PF-K-50V
C3627 ECJ2VB1H331K CAP,C 330PF-K-50V
C3628 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C4138 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C4591 ECEA1CKA101 CAP,E 100UF/16V
C4592 ECKF1H103ZF CAP,C .01UF-Z-50V
C6501 ECA1CM101 CAP,E 100UF/16V
C6502 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6503 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6504 ECJ2VC1H330J CAP,C 33PF-J-50V
C6507 ECJ2VC1H120J CAP,C 12PF-J-50V
C6509 ECJ2VC1H270J CAP,C 27PF-J-50V
C6510 ECJ2VC1H120J CAP,C 12PF-J-50V
C6511 ECA1HM010 CAP,E 1.0UF/50V
C6512 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6513 ECJ2VC1H270J CAP,C 27PF-J-50V
C6514 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6516 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6517 ECEA1HN010U CAP,E 1UF/50V
C6518 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6520 ECA1HM100 CAP,E 10UF/50V
C6521 ECEA1CKA470 CAP,E 47UF/16V
C6522 ECJ2VC1H221J CAP,C 220PF-J-50V
C6523 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C6524 ECA1HM010 CAP,E 1.0UF/50V
C6525 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6526 ECA1HM3R3 CAP,E 3.3UF/50V
C6527 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C6528 ECA1CM101 CAP,E 100UF/16V
C6529 ECEA1CN100U CAP,E 10UF-16V
C6531 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6532 ECJ2VB1H103K CAP,C .01UF-K-50V
DIODES
D001 ERA15-01 DIODE
D002 MA165 DIODE
D003 MA4047H DIODE
D006 MA4330H DIODE
D008 MA165 DIODE
D009 MA165 DIODE
D011 MA165 DIODE
D012 MA4056M DIODE
D013 MA4056M DIODE
D014 MA165 DIODE
D015 MA165 DIODE
D016 MA165 DIODE
D017 MA165 DIODE
REF NO. PART NO. DESCRIPTION
