- 40 -
Parts List
REPLACEMENT PARTS LIST
Model: CT-27DC50B
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
228-00
PARTS LIST
D025 MA4056M DIODE
D026 MA4056M DIODE
D046 MA4056M DIODE
D047 MA4056M DIODE
D451 ERA15-01 DIODE
D452 MA4047M DIODE, ZENER
D453 MA165 DIODE
D461 MA27WTA DIODE
D501 MA4082L DIODE
D531 AS01 DIODE
D532 MA4062L DIODE
D551 TVSRU2N DIODE
D554 BYD33G-163 DIODE
D555 MA165 DIODE
D556 MA4360H DIODE, ZENER
D557 TVSRU2N DIODE
D558 RS3FS DIODE
D559 BYD33G-113 DIODE
D560 MA165 DIODE
D561 BYD33G-163 DIODE
D801 EM02BM 0 DIODE
D802 EM02BM 0 DIODE
D805 TAP111M003 DIODE
D806 MA4047M DIODE, ZENER
D807 MA165 DIODE
D809 RU3YX-M DIODE
D820 EU02V1 DIODE
D821 EU02V1 DIODE
D822 EU02V1 DIODE
D823 RL30A DIODE
D824 EU02V1 DIODE
D825 TVSSR2KL DIODE, PROTECTION
D826 EU02V1 DIODE
D829 MA165 DIODE
D830 MA4270M DIODE
D856 TVSS1WBS80 DIODE
D862 AG01AV0 DIODE
D864 AU01Z DIODE
D866 1SS254T-77 DIODE, SWITCHING
D867 1SS254T-77 DIODE, SWITCHING
D868 MA4036M DIODE, ZENER
D881 MA7075 DIODE
D883 EK14V0 DIODE
D888 EK14V0 DIODE
D891 EM01ZV0 DIODE
D892 EK06V0 DIODE
D893 MA7150B R DIODE
D894 EK06V0 DIODE
D895 EK06V0 DIODE
D896 EK06V0 DIODE
REF NO. PART NO. DESCRIPTION
D2301 MA165 DIODE
D2305 MA4110M DIODE, ZENER
D2306 MA4110M DIODE, ZENER
D2307 MA4110M DIODE, ZENER
D2308 MA4110M DIODE, ZENER
D2315 MA165 DIODE
D2342 MA165 DIODE
D2343 MA165 DIODE
D3001 MA4110M DIODE, ZENER
D3002 MA4110M DIODE, ZENER
D3003 MA4110M DIODE, ZENER
D3004 MA4110M DIODE, ZENER
D3005 MA4110M DIODE, ZENER
D3006 MA4110M DIODE, ZENER
D3007 MA4110M DIODE, ZENER
D3008 MA4110M DIODE, ZENER
D3009 MA4110M DIODE, ZENER
D3010 MA4110M DIODE, ZENER
D3013 MA4110M DIODE, ZENER
D3014 MA4110M DIODE, ZENER
D3015 MA4110M DIODE, ZENER
D3016 MA4110M DIODE, ZENER
D3017 MA4110M DIODE, ZENER
D3018 MA4110M DIODE, ZENER
D3019 MA4110M DIODE, ZENER
D3020 MA4110M DIODE, ZENER
D3021 MA4110M DIODE, ZENER
D3022 MA4110M DIODE, ZENER
D3331 GP1F32T AUDIO OUTPUT
D3601 AK04V0 DIODE
D3602 AK04V0 DIODE
D3603 MA4100M DIODE, ZENER
D3604 MA4100M DIODE, ZENER
D3605 MA4110M DIODE, ZENER
D3606 MA4110M DIODE, ZENER
D3607 MA4100M DIODE, ZENER
D3608 MA4100M DIODE, ZENER
FUSES
F801 XBA2A00101 FUSE 6.3A 125V
F3601 ICP-N25 FUSE
INTEGRATED CIRCUITS
IC001 MN1876476TC1 INT CKT
IC002 M24C04-WBN6 INT CKT
IC003 RPM-637CBRL IR RECEIVER, REMOTE CONTROL
IC101 AN5166K INT CKT
IC451 LA7838 INT CKT
IC551 AN78M09-LB INT CKT
IC552 AN78M05-LB INT CKT
IC801 PC817X2 INT CKT
IC803 STR58041A INT CKT
REF NO. PART NO. DESCRIPTION
