REPLACEMENT PARTS LIST
Model: CT-27DC50B
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
- 41 -
228-00
PARTS LIST
Parts List
IC866 PC817X1 INT CKT
IC881 UPC1093J-1-T INT CKT
IC891 PQ07RX11 INT CKT
IC896 SI-3090F INT CKT
IC2201 AN5829S-E1V INT CKT
IC2302 AN5272 INT CKT
IC2321 CXA2021S INT CKT
IC3001 MM1114XFBE INT CKT
IC3002 BU4551BF-E2 INT CKT
IC3501 TC74HCT00AFL INT CKT
IC3502 TC74ACT164FL INT CKT
IC3601 PQ09DZ1U INT CKT
IC3602 NJM4580MTE1 INT CKT
IC3603 ML6427CS INT CKT
IC4591 BA6956AN INT CKT
IC6501 MN82840 INT CKT
IC6502 MN1382RTX INT CKT
COILS
L001 EXCELSA35 FERRITE BEAD
J101 EXCELSA35 FERRITE BEAD
L002 ELESN390KA COIL, PEAKING 39UH
L003 TLTABT2R2K COIL, PEAKING 2.2UH
L004 TLTABT2R2K COIL, PEAKING 2.2UH
L005 ELESN390KA COIL, PEAKING 39UH
L006 EXCELSA24T FERRITE BEAD
L008 TLUABTA470K COIL, PEAKING 47UH
L009 EXCELSA39 FERRITE BEAD
L069 EXCELSA35 FERRITE BEAD
L103 ELESN120JA COIL, PEAKING 12UH
L104 TLUABTA390K COIL, PEAKING 39UH
L105 EIV7EN053B COIL, VCO
L106 ELESN180JA COIL, PEAKING
L351 TLTABT101K COIL, PEAKING
L551 ELH5L7103 COIL
L554 EXCELSA24T FERRITE BEAD
L555 EXCELSA24T FERRITE BEAD
L556 EXCELSA24T FERRITE BEAD
L801 ELF20N020A COIL, 2UH
L803 ELF17N007A LINE FILTER
L804 EXCELSA39 FERRITE BEAD
L805 EXCELSA39 FERRITE BEAD
L861 TSKA158 COIL
L864 VLP0392-T COIL
L883 TALL08T100KA COIL
L885 ELELN100KA COIL, PEAKING 10UH
L892 ELESN330KA COIL, PEAKING 33UH
L894 ELESN330KA COIL, PEAKING 33UH
L896 TALL08T220KA TRANSFORMER, LINE FILTER
L2302 TLTABT2R2K COIL, PEAKING 2.2UH
L3001 ELESN220KA COIL, PEAKING 22UH
REF NO. PART NO. DESCRIPTION
L3010 EXCELSA35 FERRITE BEAD
L3011 EXCELSA35 FERRITE BEAD
L3012 EXCELSA35 FERRITE BEAD
L3331 ELESN220JA COIL, PEAKING 22UH
L3501 ELESN220KA COIL, PEAKING 22UH
L3601 TSKA157 COIL
L3602 TSKA157 COIL
L3603 ELESN220KA COIL, PEAKING 22UH
L3604 TSKA157 COIL
L3605 TSKA157 COIL
L6501 ELESN150KA COIL, PEAKING 15UH
L6502 ELESN330JA COIL, PEAKING 33UH
L6504 ELESN330JA COIL, PEAKING 33UH
L6505 ELESN330JA COIL, PEAKING 33UH
L6507 ELESN150KA COIL, PEAKING 15UH
L6508 EXCELSA39 FERRITE BEAD
L6510 EXCELSA35 FERRITE BEAD
TRANSISTORS
Q001 2SD601ARTX TRANSISTOR
Q002 2SC1685QRS TRANSISTOR
Q003 2SB709ARTX TRANSISTOR
Q004 2SB709ARTX TRANSISTOR
Q302 2SD601ARTX TRANSISTOR
Q303 2SB709ARTX TRANSISTOR
Q304 2SD601ARTX TRANSISTOR
Q351 2SC3063 TRANSISTOR
Q352 2SC3063 TRANSISTOR
Q353 2SC3063 TRANSISTOR
Q430 2SD601ARTX TRANSISTOR
Q451 2SD601ARTX TRANSISTOR
Q452 2SD601ARTX TRANSISTOR
Q501 2SC4212H TRANSISTOR
Q551 2SD2539LB306 TRANSISTOR
Q801 2SC1685RSTA TRANSISTOR
Q802 2SC1384RS TRANSISTOR
Q804 2SA1091-OTP2 TRANSISTOR
Q861 2SC4662LF654 TRANSISTOR
Q867 2SD1996STA TRANSISTOR
Q871 2SD1996STA TRANSISTOR
Q872 2SC3311RSTA TRANSISTOR
Q873 2SD1996STA TRANSISTOR
Q885 2SJ525TP TRANSISTOR
Q886 UN4213 TRANSISTOR
Q2302 2SB709ARTX TRANSISTOR
Q2303 2SD601ARTX TRANSISTOR
Q2362 2SB709ARTX TRANSISTOR
Q2363 2SD601ARTX TRANSISTOR
Q2364 2SB709ARTX TRANSISTOR
Q2409 2SD601ARTX TRANSISTOR
Q2410 2SD601ARTX TRANSISTOR
REF NO. PART NO. DESCRIPTION
