CS-MC95KE CU-3MC205KE
Unit
Single Operation
(A, B1, B2)
Single Operation Double Operation Trible
Operation
(A) (B1 or B2) (B1 + B2) (A + B1 or B2) (A + B1 + B2)
Cooling Capacity Per Unit kW
kcal/h
— 2.40-2.34
2,060-2,010
2.82-2.78
2,430-2,390
3.60-3.52
3,100-3,030
5.22-5.12
4,490-4,400
6.00-5.86
5,160-5,040
Moisture Removal l/h
Pint/h
— 1.5
3.2
1.6
3.4
2.1
4.4
2.8
5.9
3.2
6.8
Power Source Phase
V
Cycle
Single
230 - 220
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min
(cfm)
6.6 - 6.2
(230 - 220)
—
Indoor Air (Me) m
3
/min
(cfm)
7.2 - 6.8
(260 - 240)
—
Indoor Air (Hi) m
3
/min
(cfm)
8.7 - 8.4
(310 - 300)
—
Indoor Air (SHi) m
3
/min
(cfm)
10.1 - 10.0
(360 - 350)
—
Noise Level dB (A) High 36 - 35,
Low 26 - 26
High 56 - 54
Electrical
Data
Input kW 0.030 - 0.025 0.79 - 0.75 1.09 - 1.05 1.15 - 1.10 1.79 - 1.70 1.83 - 1.77
Running Current A 0.14 - 0.13 3.36 - 3.47 4.76 - 4.77 4.92 - 5.04 7.62 - 7.74 7.78 - 8.01
EER W/W
(kcal/hW)
— 2.93 - 3.04
(2.51 - 2.61)
2.52 - 2.60
(2.17 - 2.23)
2.98 - 3.06
(2.56 - 2.63)
2.82 - 2.93
(2.43 - 2.51)
3.13 - 3.18
(2.69 - 2.74)
Starting Current A (A unit) 15.5 - 15.0 (B unit) 21.5 - 21.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 3/8”
L (liquid side) ; 1/4”
G (gas side) ; 3/8”
L (liquid side) ; 1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.7 —
Power Cord Length
Number of core-wire
m 2.0
3 (1.0 mm
2
)
—
—
Dimensions Height inch (mm) 10 - 31/32 (279) 25 - 21/32 (651)
Width inch (mm) 31 - 15/32 (799) 35 - 3/16 (893)
Depth inch (mm) 7 - 27/32 (199) 13 - 19/32 (345)
Net Weight lb (kg) 20 (9.0) 141 (64)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 650 + 900
Air
Circulation
Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber
30%
AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 27.8 - 26.3 121.82 - 107.91
Rated Output W 15 37
Fan Speed Low rpm 880 - 820 —
Medium rpm 960 - 900 —
High rpm 1,155 - 1,110 765 - 725
SuperHigh rpm 1,335 - 1,320 —
