Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 14 2 × 24
FPI 18 16
Size (W × H × L) mm 624 × 294 × 25.4 560 × 609.6 × 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(270)
Refrigerant (R-22) g (oz) — 710 × 2 (25.0 × 2)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — 680
Flow Rate l/min — 11.5
Inner Diameter mm — 1.5
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 25 µF, 370 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 3.0 µF, 450 VAC
•
Specifications are subject to change without notice for further improvement.
9
CS-MC95KE CU-MC145KE / CS-MC95KE CU-MC185KE / CS-MC95KE CU-3MC205KE / CS-MC125KE CU-MC245KE / CS-MC76KE / CS-MC126KE CU-MC196KE
