Panasonic CU-MC145KE - Page 14

Unit
(A)
CS-MC126KE
(B)
CS-MC76KE
CS-MC196KE
Cooling Capacity kW
kcal/h
(A) 3.55 - 3.52
(A) 3,050 - 3,030
(B) 2.08 - 2.06
(B) 1,790 - 1,770
(A+B) 5.63 - 5.58
(A+B) 4,840 - 4,800
Moisture Removal l/h
Pint/h
(A) 2.1
4.4
(B) 1.4
3.0
(A+B) 3.1
6.6
Power Source Phase
V
Cycle
Single
230 - 220
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) 6.1 - 6.2 (220 - 220) 5.5 - 4.8 (190 -170) —
Indoor Air (Me) m
3
/min (cfm) 7.8 - 7.9 (280 - 280) 5.7 - 5.1 (200 - 180) —
Indoor Air (Hi) m
3
/min (cfm) 9.0 - 8.8 (320 - 310) 7.0 - 6.8 (250 -240) —
Indoor Air (SHi) m
3
/min (cfm) 9.7 - 9.4 (340 - 330) 7.9 - 6.8 (280 -240) —
Noise Level dB (A) (A) High 39 - 39
Low 29 - 29
(B) High 33 - 32
Low 26 - 26
High 55 - 53
Electrical Data Input W (A) 1,250 - 1,230 (B) 750 - 720 (A+B) 1,880 -1,840
Running Current A (A) 5.60 - 5.70 (B) 3.90 - 3.70 (A+B) 9.00 - 8.90
EER W/W
(kcal/hW)
(A) 2.84 - 2.86
(2.44 - 2.46)
(B) 2.77 - 2.86
(2.39 - 2.46)
(A+B) 40 - 38
(2.57 - 2.61)
Starting Current A (A) 25 - 24 (B) 15 - 14 (A+B) 40 - 38
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”,3/8”
L ; Half Union 1/4”, 1/4”
G ; 3-way valve 1/2”,3/8”
L ; 2-way valve 1/4”,1/4”
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 1/2”,3/8”
L (liquid side) ; 1/4”, 1/4”
G (gas side) ; 1/2”,3/8”
L (liquid side) ; 1/4”,1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.7 —
Power Cord Length
Number of core-wire
m 2.0
3 (1.0 mm
2
)
—
—
Dimensions Height inch (mm) 10 - 31/32 (279) 25 - 21/32 (651)
Width inch (mm) 31 - 15/32 (799) 35 - 3/16 (893)
Depth inch (mm) 7 - 27/32 (199) 13 - 19/32 (345)
Net Weight lb (kg) 20 (9.0) 148 (67)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W (A) 1,100 (B) 600 (A+B) 1,700
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 30% AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W (A) 28.7 - 27.1 (B) 20.6 - 19.1 121.82 - 107.91
Rated Output W (A) 15 (B) 10 37
Fan Speed Low rpm (A) 835 - 890 (B) 810 - 835 —
Medium rpm (A) 1,075 - 1,125 (B) 840 - 875 —
High rpm (A) 1,235 - 1,260 (B) 1,030 - 1,175 740 - 725
SuperHigh rpm (A) 1,330 - 1,340 (B) 1,160 - 1,175 —
