Flap Setting for Each Air Outlet
Lock individual ap
When setting the ap for each air outlet individually according to the
room condition
• Even if the ap setting of all indoor units (P.9) or each indoor unit (P.12) is changed,
the ap directions set here are not changed.
1
Display the menu screen.
To return to the previous screen
Press .
2
Select [Lock indiv. ap].
▲ ▼ →
3
Select the indoor unit to set.
▲ ▼ → ►
e.g. 1-1 → 1-2 to 1-8
4
Select the air outlet.
▲ ▼ → ►
• The square mark
(indented ) on the
panel of the indoor
unit indicates air outlet
No. 1. There are some
models that do not have a square mark
(indented ).
• The air outlet No. changes according to
the installation direction. Check by actual
operation.
• ALL: All the air outlets
5
Select the ap direction.
▲ ▼ →
(Press 2 times to nish.)
* For types other than the 4-way cassette
type, the following display appears and
this function cannot be used.
1
2
3
4
Swing
Unlock
