Panasonic CZ-RTC5B

8
(EN)
Basic Operations
1
Start operation.
Press
.
(The operation indicator illuminates.)
 To change the setting
(P.10)
 To turn the energy saving
operation ON/OFF
Press during operation.
(Only for models equipped with the
energy saving function.)
 Start/Stop
2
Select the item to set.
Press ◄ ►.
3
Change the setting.
Press ▲▼ → .
(The cursor disappears.)
Energy saving operation
is in process.
Operation indicator
Note
z Operation modes that cannot be set are not displayed.
z
The swing and airow direction on the remote control is not synchronised with the ap movement.
z The ap display differs from the actual ap angle.
z Pressing
after recovery from mains power failure will resume operation with
the contents before mains power failure has occurred.
z If no operation is performed for a certain period of time, the backlight turns off to
save electricity. (Press any button for illumination.)
z The energy saving operation restricts the maximum current value, resulting in
decreased cooling/heating performance.
(If the current of outdoor units does not reach the peak due to low load operation,
the current value is not restricted.)
z
For models that cannot change the airow direction, the airow direction is not displayed.
z When restricting the set temperature range (P.31)
z
The fan speed and airow direction in cooling/drying operation can be adjusted with 3
levels if controlling using one remote controller while assigning an indoor unit (e.g. ceiling-
hung type) which has a 3-level adjustment of fan speed and airow direction in cooling /
drying operation as main unit, and assigning a 4-way ceiling cassette type as sub unit.
