3. Error Code List
The error code consists of 8 bits data and it shows the following information.
Attribute Main item Sub item Error code Contents (Upper) Error Indication
High 4bits Low 4 bits Check point (Lower) Detecting
device
Part/Circuit
LENS Lens drive OIS 18*0 1000 PSD (X) error. Hall element (X axis) position detect
error in OIS unit.
OIS X LENSu NG
OIS Unit
2000 PSD (Y) error. Hall element (Y axis) position detect
error in OIS unit.
OIS Y
OIS Unit
3000 GYRO (X) error. Gyro (IC7101) detect error on Main
P. C . B. .
JYRO X JYRO NG
IC7101 (Gyro element) or IC6001 (VENUS HD)
4000 GYRO (Y) error. Gyro (IC7101) detect error on Main
P. C . B. .
JYRO Y
IC7101 (Gyro element) or IC6001 (VENUS HD)
5000 MREF error (Reference voltage error). OIS REF LENSSd/DSP
NG
IC9101 (LENS drive) or IC6001 (VENUS HD)
6000 Drive voltage (X) error. OISX REF LENSu/LENS
FPC
LENS Unit, LENS flex breaks, IC6001(VENUS HD)
AD value error, etc.
7000 Drive voltage (Y) error. OISY REF
LENS Unit, LENS flex breaks, IC6001(VENUS HD)
AD value error, etc.
Zoom
(C.B.)
0?10 Collapsible barrel Low detect error ZOOM L ZOOMm/
LENSu
(Collapsible barrel encoder always detects Low.)
Mechanical lock, FP9005-(26) signal line or IC6001
(VENUS HD)
0?20 Collapsible barrel High detect error ZOOM H
(Collapsible barrel encoder always detects High.)
Mechanical lock, FP9005-(26) signal line or IC6001
(VENUS HD)
0?30 Zoom motor sensor error. ZOOM ENC
Mechanical lock, FP9005-(37), (40) signal line or
IC6001 (VENUS HD)
0?40 Zoom motor sensor error. (During monitor mode.)
Mechanical lock, FP9005-(37), (40) signal line or
IC6001 (VENUS HD)
0?50 Zoom motor sensor error. (During monitor mode with
slow speed.)
Mechanical lock, FP9005-(37), (40) signal line or
IC6001 (VENUS HD)
Focus 0?01 HP High detect error
(Focus encoder always detects High, and not
becomes Low)
FOCUS L LENS FPC/
DSP
Mechanical lock, FP9005-(26) signal line or IC6001
(VENUS HD)
0?02 HP Low detect error
(Focus encoder always detects Low, and not
becomes High)
FOCUS H
Mechanical lock, FP9005-(26) signal line or IC6001
(VENUS HD)
Lens 18*1 0000 Power ON time out error. LENS DRV LENSu
Lens drive system
18*2 0000 Power OFF time out error.
Lens drive system
Adj.History OIS 19*0 2000 OIS adj. Yaw direction amplitude error (small) OIS ADJ OIS ADJ
3000 OIS adj. Pitch direction amplitude error (small)
4000 OIS adj. Yaw direction amplitude error (large)
5000 OIS adj. Pitch direction amplitude error (large)
6000 OIS adj. MREF error
7000 OIS adj. time out error
8000 OIS adj. Yaw direction off set error
9000 OIS adj. Pitch direction off set error
A000 OIS adj. Yaw direction gain error
B000 OIS adj. Pitch direction gain error
