Panasonic DMC-TZ7EB - Page 19

19
C000 OIS adj. Yaw direction position sensor error
D000 OIS adj. Pitch direction position sensor error
E000 OIS adj. other error
HARD VENUS
A/D
Flash 28*0 0000 Flash charging error. STRB CHG STRB PCB/
FPC
IC6001-(AA17) signal line or Flash charging circuit
FLASH
ROM
(EEPROM
Area)
FLASH
ROM
(EEPROM
Area)
2B*0 0001
0003
0004
EEPROM read error FROM RE FROM
IC6002 (FLASH ROM)
0002 EEPROM write error FROM WR FROM
IC6002 (FLASH ROM)
0005 Firmware version up error (No indication) (No indication)
Replace the firmware file in the SD memory card.
0008
0009
SDRAM error
SDRAM Mounting defective
SYSTEM RTC 2C*0 0001 SYSTEM IC initialize failure error SYS INIT MAIN PCB
Communication between IC6001 (VENUS HD) and
IC9101 (SYSTEM)
SOFT CPU Reset 30*0 0001
|
0007
NMI reset
Non Mask-able Interrupt
(30000001-30000007 are caused by factors)
NMI RST MAIN PCB
Card Card 31*0 0001 Card logic error SD CARD SD CARD/
DSP
SD memory card data line or IC6001 (VENUS HD)
0002 Card physical error
SD memory card data line or IC6001 (VENUS HD)
0004 Write error SD WRITE
SD memory card data line or IC6001 (VENUS HD)
39*0 0005 Format error INMEMORY FROM
CPU, Stop 38*0 0001 Camera task finish process time out. LENS COM LENSu/DSP
ASIC hard Communication between Lens system and IC6001
(VENUS HD)
0002 Camera task invalid code error. DSP DSP
IC6001 (VENUS HD)
0100 File time out error in recording motion image
IC6001 (VENUS HD)
0200 File data cue send error in recording motion image
IC6001 (VENUS HD)
0300 Single or burst recording brake time out.
Memory
area
3A*0 0008 work area partitioning failure (No indication) (No indication)
USB dynamic memory securing failure when con-
necting
Operation Power on 3B*0 0000 FLASHROM processing early period of camera dur-
ing movement.
INIT (No indication)
Zoom Zoom 3C*0 0000 Imperfect zoom lens processing ZOOM ZOOMm/
LENSu
Zoom lens
35*0 0000
|
FFFF
Software error
(0-7bit : command, 8-15bit : status)
DSP DSP
35*1 0000 Though record preprocessing is necessary, it is not
called.
35*2 0000 Though record preprocessing is necessary, it is not
completed.
(No indication) (No indication)
Attribute Main item Sub item Error code Contents (Upper) Error Indication
High 4bits Low 4 bits Check point (Lower) Detecting
device
Part/Circuit
