Panasonic DMR-XW380EB

DMR-XW380EBK vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
D11301 B0BC03200002 DIODE 1 E.S.D.
## RFKB71181FT MAIN P.C.B. 1 (RTL) E.S.D. D11302 B0BA01600007 DIODE 1 E.S.D.
## VEP73177C AV IO P.C.B. 1 (RTL) E.S.D. D11303 B0ACCE000003 DIODE 1 E.S.D.
## VEP70352A FRONT (L) P.C.B. 1 (RTL) E.S.D. D11304 B0HAGM000006 DIODE 1 E.S.D.
## VEP70354A FRONT (R) P.C.B. 1 (RTL) E.S.D. D11305 B0BC01000014 DIODE 1 E.S.D.
## VEP77159A T2 TUNER PACK P.C.B. 1 (RTL) E.S.D. D11306 B0HADV000001 DIODE 1 E.S.D.
D13201 B0JBSG000057 DIODE 1 E.S.D.
D14201 B0JCMD000014 DIODE 1 E.S.D.
D14202 B0JCMD000014 DIODE 1 E.S.D.
## RFKB71181FT MAIN P.C.B. (RTL) E.S.D. D14301 B0JCMD000014 DIODE 1 E.S.D.
D14302 B0JCMD000014 DIODE 1 E.S.D.
C1601 F2A1E3310075 25V 330U 1
C1611 F1H1H103A219 50V 0.01U 1  F11101 K5G202Y00006 FUSE 1
C1612 F1H1A105A028 10V 1U 1
C1613 F1H1A105A028 10V 1U 1 IC1601 C0EBK0000206 IC 1 E.S.D.
C1621 F1H1A105A028 10V 1U 1 IC1611 C0CBCBD00008 IC 1 E.S.D.
C1622 F1J0J106A014 6.3V 10U 1 IC1621 C0DBEYY00016 IC 1 E.S.D.
C1623 F1H1C104A071 16V 0.1U 1 IC6803 RFKFM24TBE2T IC 1 E.S.D.
C3801 F1H1H102A013 50V 1000P 1 IC11301 C0DACZH00017 IC 1 E.S.D.
C3803 F1H1H102A013 50V 1000P 1 IC12201 C0DAEYY00022 IC 1 E.S.D.
C6801 F1H1H103A219 50V 0.01U 1 IC14201 C0DBAYY00602 IC 1 E.S.D.
C6805 F1J0J226A014 6.3V 22U 1 IC14301 C0DBAYY00624 IC 1 E.S.D.
C6806 F1J0J226A014 6.3V 22U 1
C6807 F1J0J106A014 6.3V 10U 1  IP7501 K5H501Z00005 IC PROTECTOR 1
C6812 F1H1C104A071 16V 0.1U 1
C7501 F2A1C221B111 16V 220U 1 JK3801 K2HA107B0002 JACK, VIDEO/AUDIO IN 1
C7503 F1H1H392A013 50V 3900 1
C7504 F2A1C221B111 16V 220U 1 L1601 G0C100K00043 COIL 10UH 1
C7505 F2A1V560A387 35V 56U 1 L1602 G0C100K00043 COIL 10UH 1
C7506 F2A1H220A455 50V 22U 1 L7501 G0C390JA0055 COIL 39UH 1
C7507 F2A1H220A455 50V 22U 1  L11101 G0B273E00006 COIL 1
C7933 F4D55473A013 5.5V 0.047 1  L11102 G0B273E00006 COIL 1
C10101 F1H1H221A004 50V 220P 1 L13201 G0A100H00025 COIL 10UH 1
 C11101 F0CAF683A021 100V 0.068P 1 L14203 G0A100ZA0045 COILޓ10UH 1
 C11102 F1B2G471A014 400V 470P 1 L14302 G0A100ZA0045 COILޓ10UH 1
 C11103 F1B2G471A014 400V 470P 1
C11107 F2B2W4700003 450V 47U 1 LB3801 J0JBC0000011 COIL 1
 C11109 F1B2G222A018 400V 2200P 1 LB3802 J0JBC0000011 COIL 1
 C11111 F0CAF683A021 100V 0.068P 1 LB3803 ERJ3GEY0R00V 1/10W 0 1
C11301 F1B3D391A011 390U 1 LB6801 J0JHC0000032 COIL 1
C11302 F1H1H222A013 50V 2200P 1 LB6802 J0JCC0000185 COIL 1
C11303 F2A1V2210081 35V 220U 1 LB6803 J0JGC0000020 COIL 1
C11304 F1H1H101A004 50V 100P 1 LB6804 J0JCC0000185 COIL 1
C11305 F1H1H472A013 50V 4700P 1 LB7501 ERJ3GEY0R00V 1/10W 0 1
C12202 F1H1C104A071 16V 0.1U 1 LB7502 ERJ3GEY0R00V 1/10W 0 1
C12203 F1H1C104A071 16V 0.1U 1 LB11103 J0JKB0000003 COIL 1
C13101 F1H1A105A028 10V 1U 1 LB11104 J0JHC0000048 COIL 1
C13103 F2A1C3300040 16V 33U 1 LB14201 J0JHC0000048 COIL 1
C13201 F2A1C1520021 16V 1500U 1 LB14301 ERJ6GEY0R00V 1/8W 0 1
C13202 F2A1C1520021 16V 1500U 1
C13203 F2A1C8210008 16V 820U 1 P1602 K1KA04AA0301 CONNECTOR(4P) 1
C14201 F1K1C1060001 16V 10U 1 P1603 K1KA04AA0193 CONNECTOR(4P) 1
C14202 F1K1C1060001 16V 10U 1 P6701 K1KY23AA0606 CONNECTOR(23P) 1
C14203 F1J1E105A080 25V 1U 1 P6702 K1KY09AA0606 CONNECTOR(9P) 1
C14204 F1H1C104A071 16V 0.1U 1 P6703 K1KY23AA0606 CONNECTOR(23P) 1
C14205 F1H1H561A004 50V 560P 1 P6801 K1NA12B00005 SD CARD CONNECTOR 1
C14206 F1H1C104A071 16V 0.1U 1 P6802 K1FY104B0006 DV IN CONNECTOR(4P) 1
C14218 F2A1C8210008 16V 820U 1 P6804 K1FY104B0037 CONNECTOR 1
C14300 F1J1C1060001 16V 10U 1 P7501 K1KB12B00040 CONNECTOR(12P) 1
C14301 F1J1C1060001 16V 10U 1  P11101 K2AA2B000017 AC INLET 1
C14302 F1J1C1060001 16V 10U 1
C14303 F1H1C104A071 16V 0.1U 1 Q7501 B1ADLB000006 TRANSISTOR 1 E.S.D.
C14304 F1H1H332A013 50V 3300P 1 Q7502 B1BACG000058 TRANSISTOR 1 E.S.D.
C14305 F1H1C104A071 16V 0.1U 1 Q7503 B1ABGC000011 TRANSISTOR 1 E.S.D.
C14307 F1H1C104A071 16V 0.1U 1 Q10101 B1ABDF000033 TRANSISTOR 1 E.S.D.
C14315 F2A1C8210008 16V 820U 1  Q10102 B3PBA0000454 TRANSISTOR 1 E.S.D.
 Q12201 B3PBA0000454 TRANSISTOR 1 E.S.D.
D7501 B0BA03600021 DIODE 1 E.S.D. Q13102 B1CHQD000010 TRANSISTOR 1 E.S.D.
D7502 B0AACK000004 DIODE 1 E.S.D. Q14202 B1CHRD000024 TRANSISTOR 1 E.S.D.
D7503 B0AADM000003 DIODE 1 E.S.D. Q14301 B1DHDD000022 TRANSISTOR 1 E.S.D.
D7504 B0JAMD000026 DIODE 1 E.S.D. Q14302 B1CFRD000023 TRANSISTOR 1 E.S.D.
D7505 B0AADM000003 DIODE 1 E.S.D.
D7506 B0BA02100019 DIODE 1 E.S.D. QR7501 B1GBCFJJ0040 TRANSISTOR 1 E.S.D.
D7507 B0BA01900005 DIODE 1 E.S.D. QR7502 B1GDCFNN0024 TRANSISTOR 1 E.S.D.
D10101 B0ACCK000005 DIODE 1 E.S.D. QR10101 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
D10102 B0ACCK000005 DIODE 1 E.S.D. QR10103 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
D11101 B0EDKT000009 DIODE 1 E.S.D. QR13101 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
S-46
