Panasonic DMR-XW380EB

S-4
REF No. PIN No. REC PB EE
IC8701 1 - - -
IC8701 2 - - -
IC8701 3 0.1 0.1 0.1
IC8701 4 0.1 0.1 0.1
IC8701 5 1.6 1.6 1.6
IC8701 6 0 0 0
IC8701 7 1.2 1.2 1.2
IC8701 8 1.2 1.2 1.2
IC8701 9 0 0 0
IC8701 10 0 0 0
IC8701 11 3.3 3.3 3.3
IC8701 12 3.2 3.2 3.2
IC8701 13 - - -
IC8701 14 1.2 1.2 1.2
IC8701 15 0 0 0
IC8701 16 - - -
IC8701 17 - - -
IC8701 18 0 0 0
IC8701 19 1.2 1.2 1.2
IC8701 20 1.2 1.2 1.2
IC8701 21 0 0 0
IC8701 22 - - -
IC8701 23 - - -
IC8701 24 - - -
IC8701 25 - - -
IC8701 26 0 0 0
IC8701 27 3.3 3.3 3.3
IC8701 28 0.6 0.6 0.6
IC8701 29 3.2 3.2 3.2
IC8701 30 1.2 1.2 1.2
IC8701 31 0 0 0
IC8701 32 0 0 0
IC8701 33 0 0 0
IC8701 34 0 0 0
IC8701 35 0 0 0
IC8701 36 1.2 1.2 1.2
IC8701 37 3.1 3.1 3.1
IC8701 38 3.3 3.3 3.3
IC8701 39 0 0 0
IC8701 40 1.2 1.2 1.2
IC8701 41 1.2 1.2 1.2
IC8701 42 0 0 0
IC8701 43 0 0 0
IC8701 44 1.2 1.2 1.2
IC8701 45 2.5 2.5 2.5
IC8701 46 - - -
IC8701 47 - - -
IC8701 48 0 0 0
IC8701 49 1.2 1.2 1.2
IC8701 50 1.2 1.2 1.2
IC8701 51 0 0 0
IC8701 52 2.5 2.5 2.5
IC8701 53 0.1 0.1 0.1
IC8701 54 3.3 3.3 3.3
IC8701 55 0 0 0
IC8701 56 1.2 1.2 1.2
IC8701 57 3.2 3.2 3.2
IC8701 58 0.6 0.6 0.6
IC8701 59 3.3 3.3 3.3
IC8701 60 0 0 0
IC8701 61 1.2 1.2 1.2
IC8701 62 - - -
IC8701 63 - - -
IC8701 64 1.6 1.6 1.6
IC8702 1 - - -
IC8702 2 - - -
REF No. PIN No. REC PB EE
IC8702 3 0.1 0.1 0.1
IC8702 4 0.1 0.1 0.1
IC8702 5 1.6 1.6 1.6
IC8702 6 0 0 0
IC8702 7 1.2 1.2 1.2
IC8702 8 1.2 1.2 1.2
IC8702 9 0 0 0
IC8702 10 0 0 0
IC8702 11 3.3 3.3 3.3
IC8702 12 3.2 3.2 3.2
IC8702 13 - - -
IC8702 14 1.2 1.2 1.2
IC8702 15 0 0 0
IC8702 16 - - -
IC8702 17 - - -
IC8702 18 0 0 0
IC8702 19 1.2 1.2 1.2
IC8702 20 1.2 1.2 1.2
IC8702 21 0 0 0
IC8702 22 - - -
IC8702 23 - - -
IC8702 24 - - -
IC8702 25 - - -
IC8702 26 0 0 0
IC8702 27 3.3 3.3 3.3
IC8702 28 0.6 0.6 0.6
IC8702 29 3.2 3.2 3.2
IC8702 30 1.2 1.2 1.2
IC8702 31 0 0 0
IC8702 32 0 0 0
IC8702 33 0 0 0
IC8702 34 0 0 0
IC8702 35 0 0 0
IC8702 36 1.2 1.2 1.2
IC8702 37 3.1 3.1 3.1
IC8702 38 3.3 3.3 3.3
IC8702 39 0 0 0
IC8702 40 1.2 1.2 1.2
IC8702 41 1.2 1.2 1.2
IC8702 42 0 0 0
IC8702 43 0 0 0
IC8702 44 1.2 1.2 1.2
IC8702 45 2.5 2.5 2.5
IC8702 46 - - -
IC8702 47 - - -
IC8702 48 0 0 0
IC8702 49 1.2 1.2 1.2
IC8702 50 1.2 1.2 1.2
IC8702 51 0 0 0
IC8702 52 2.5 2.5 2.5
IC8702 53 0.1 0.1 0.1
IC8702 54 3.3 3.3 3.3
IC8702 55 0 0 0
IC8702 56 1.2 1.2 1.2
IC8702 57 3.2 3.2 3.2
IC8702 58 0.6 0.6 0.6
IC8702 59 3.3 3.3 3.3
IC8702 60 0 0 0
IC8702 61 1.2 1.2 1.2
IC8702 62 - - -
IC8702 63 - - -
IC8702 64 1.6 1.6 1.6
IC8703 1 3.1 3.1 3.1
IC8703 2 0 0 0
IC8703 3 1.2 1.2 1.2
IC8703 4 5 5 5
REF No. PIN No. REC PB EE
IC8703 5 5.9 5.9 5.9
IC8704 1 1.2 1.2 1.2
IC8704 2 - - -
IC8704 3 0 0 0
IC8704 4 1.2 1.2 1.2
IC8704 5 3.2 3.2 3.2
IC8704 6 - - -
IC8704 7 - - -
IC8704 8 1.8 1.8 1.8
IC8705 1 3.2 3.2 3.2
IC8705 2 0 0 0
IC8705 3 1.2 1.2 1.2
IC8705 4 5 5 5
IC8705 5 5.9 5.9 5.9
IC8706 1 1.2 1.2 1.2
IC8706 2 - - -
IC8706 3 0 0 0
IC8706 4 1.2 1.2 1.2
IC8706 5 3.2 3.2 3.2
IC8706 6 - - -
IC8706 7 - - -
IC8706 8 1.8 1.8 1.8
IC8707 1 3.2 3.2 3.2
IC8707 2 0 0 0
IC8707 3 - - -
IC8707 4 3.3 3.3 3.3
IC8707 5 3.9 3.9 3.9
IC8708 1 3.2 3.2 3.2
IC8708 2 0 0 0
IC8708 3 - - -
IC8708 4 2.5 2.5 2.5
IC8708 5 3.9 3.9 3.9
IC8709 1 3.3 3.3 3.3
IC8709 2 3.1 3.1 3.1
IC8709 3 1.8 1.8 1.8
IC8709 4 0.9 0.9 0.9
IC8709 5 0 0 0
IC8710 1 3.1 3.1 3.1
IC8710 2 0 0 0
IC8710 3 - - -
IC8710 4 3.3 3.3 3.3
IC8710 5 5.9 5.9 5.9
IC8711 1 3.2 3.2 3.2
IC8711 2 0 0 0
IC8711 3 - - -
IC8711 4 3.3 3.3 3.3
IC8711 5 3.9 3.9 3.9
S2.4. T2_Tuner Pack P.C.B.
